GSDML File (Device Description File)

4.3
To configure a PROFINET controller, the configuration tool needs a GSDML file for each type of device in the network. The GSDML file is a
PROFINET xml file containing the necessary communication setup data for a device. Each product in the iC7 series has a unique GSDML
file.
Download the GSDML files for the iC7 series from
figuration-files/. Check that the GSDML file version is compatible with the firmware version.

Reference and Main Actual Handling

4.4
Propulsion & Machinery Application
4.4.1
For the Propulsion & Machinery application the Main Reference [REF] and the Main Actual Value [MAV] are tied to the motor speed. These
variables are interfaced as signed 16-bit integer values and are both scaled linearly based on the signal and scale parameter pairs given
in Table 15.
Table 15: Reference Scaling Parameters
Menu Parameter
index
2.2.2.1.20 Fieldbus Speed Signal Max
2.2.2.1.21 Fieldbus Speed Signal Min
2.2.2.1.22 Fieldbus Speed Scale Max
2.2.2.1.23 Fieldbus Speed Scale Min
Danfoss Drives Oy © 2024.04
Parameter Value
number
7080 Accepted characters:
• Lower case letters (a–z)
• Numbers (0–9)
• Special characters: dash (–), full stop (.)
The value can be up to 127 characters or
digits in total. The maximum length for
each component separated by a full stop
or dash is 63 characters or digits. Spaces
are not allowed.
https://www.danfoss.com/en/service-and-support/downloads/dds/fieldbus-con-
Parameter Unit
number
6312 -
6313 -
6310 [Hz]
6311 [Hz]
Additional information
Each PROFINET device has
a unique Name of Station.
Range
-32768–32767
-32768–32767
-1000–1000
-1000–1000
