Table 5: Communication Profiles and Supported Applications for iC7-Hybrid
Profile
PROFIdrive Application Class 0
PROFIenergy version 1.3
PROFIdrive standard PNUs
iC Hybrid Profile

iC7 Hybrid Profile

2.3

Overview

2.3.1
The iC Hybrid profile is used in the iC7 series with the Grid Converter and DC/DC Converter applications.

Control Word

2.3.2
Table 6: Control Word Bits in iC Hybrid Profile
Bit Name
0 Switch On Enabled
1 MCB Close Enabled
2 Quick Stop
3 Start
4 Pre-charge
5 –
6 –
7 Warning/Fault Reset
8 –
9 –
10 Data Valid
Danfoss Drives Oy © 2024.04
Grid Converter
X
X
X
X
Description
0: Pre-charging
prevented or interrupted. If the main circuit breaker is closed, it is
(1)
opened .
1: Pre-charging
prevented or interrupted.
0: Closing the main circuit breaker is prevented
breaker is opened
1: Closing the main circuit breaker is not prevented
0: Activate Quick Stop.
1: Do not activate Quick Stop.
0: Stop the unit if it is running, or stop the startup sequence if it is not
completed.
1: Initiate the startup sequence (DC-link precharging
circuit breaker
0: Stop the DC-link precharging, if ongoing.
1: Start or continue the DC-link precharging.
Reserved
Reserved
0: No action.
1: Reset active warnings/faults.
Reserved
Reserved
0: Ignore the current incoming process data values, instead use the last
processed value when the Data Valid bit was true.
1: Use the current incoming process data values.
DC/DC Converter
X
X
X
X
(1)
, closing the main circuit breaker
(1)
, closing the main circuit breaker
(1)
, and running is prevented or interrupted.
(2)
, and start running), or keep the unit running.
AQ481922002453en-000101 / 172K4283A |
(1)
, and running are
(1)
, and running are not
(1)
or the main circuit
(1)
.
(2)
, closing the main
11
