Design Guide | VLT® AutomationDrive FC 360
Table 13: Motor Cable Terminals Providing Clockwise Rotation (Factory Default)
Terminal
96
97
98
99
The direction of rotation can be changed by switching 2 phases in the motor cable, or by changing the setting of parameter 4-10 Motor
Speed Direction.
1
U V
2 2
U V
1 1
2
96 97
U V
1
2 2
U V
1 1
2
96 97
Figure 26: Changing Motor Rotation
Motor Thermal Protection
7.6.2
The electronic thermal relay in the drive has received approval for single motor overload protection, when parameter 1-90 Motor
Thermal Protection is set for ETR Trip and parameter 1-24 Motor Current is set to the rated motor current (see the motor nameplate).
Parallel Connection of Motors
7.6.3
The drive can control several parallel-connected motors. For different configurations of parallel-connected motors, see
58
| Danfoss A/S © 2024.01
W
2
W
1
98
W
2
W
1
98
Function
U/T1
V/T2
W/T3
Ground
Figure 27.
