Design Guide | VLT® AutomationDrive FC 360
Table 68: Analog Speed Reference (Current)
FC
+ 24 V 12
18
D IN
19
D IN
D IN 27
29
D IN
D IN 31
D IN 32
D IN 33
+ 10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
Table 69: Speed Reference (Using a Manual Potentiometer)
FC
+ 24 V 12
18
D IN
D IN 19
D IN
27
D IN
29
D IN 31
D IN 32
D IN 33
+ 10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
122
| Danfoss A/S © 2024.01
Parameter function
Parameter 6-22 Terminal 54 Low Current
Parameter 6-23 Terminal 54 High Current
Parameter 6-24 Terminal 54 Low Ref./
Feedb. Value
Parameter 6-25 Terminal 54 High Ref./
Feedb. Value
Parameter 6-29 Terminal 54 mode
*=Default value
Notes/comments:
+
-
4 - 20mA
Parameter function
Parameter 6-10 Terminal 53 Low Voltage
Parameter 6-11 Terminal 53 High Voltage
Parameter 6-14 Terminal 53 Low Ref./
Feedb. Value
Parameter 6-15 Terminal 53 High Ref./
Feedb. Value
Parameter 6-19 Terminal 53 mode
*=Default value
Notes/comments:
≈ 5k Ω
Parameter setting
*4 mA
*20 mA
*0
50 Hz
[0] Current
Parameter setting
*0.07 V
*10 V
*0
50 Hz
*[1] Voltage
AJ435824192086en-000101 / 130R1295
