Design Guide | VLT® AutomationDrive FC 360
Product Overview and Features
3
Power Ratings, Weights, and Dimensions
3.1
For enclosure sizes and power ratings of the drives, refer to the following table. For more dimensions, see the chapter Exterior and
Terminal Dimensions.
Table 2: Power Ratings, Weights, and Dimensions, Enclosure Sizes J8–J9, 380–480 V
Enclosure size
IP
NEMA
Shipping dimensions [mm (in)]
Drive dimensions [mm (in)]
Maximum weight [kg (lb)]
Automated Operational Features
3.2
Introduction
3.2.1
Automated operational features are active when the drive is operating. Most of them require no programming or setup. The drive has a
range of built-in protection functions to protect itself and the motor when it runs.
For details of any setup required, in particular motor parameters, refer to the programming guide.
Short-circuit Protection
3.2.2
Motor (phase-to-phase)
The drive is protected against short circuits on the motor side by current measurement in each of the 3 motor phases. A short circuit
between 2 output phases causes an overcurrent in the inverter. The inverter is turned off when the short-circuit current exceeds the
allowed value (Alarm 16, Trip Lock).
Mains side
A drive that works correctly limits the current it can draw from the supply. Still, it is recommended to use fuses and/or circuit breakers on
the supply side as protection if there is component break-down inside the drive (1st fault).
To ensure compliance with IEC 60364 for CE, it is mandatory to use fuses and/or circuit breakers.
14
| Danfoss A/S © 2024.01
Height
Width
Depth
Height
Width
Depth
NOTICE
J8
20
Chassis
587 (23)
997 (39)
460 (18)
909 (36)
250 (10)
375 (15)
98 (216)
J9
20
Chassis
587 (23)
1170 (46)
535 (21)
1122 (44)
350 (14)
375 (15)
164 (362)
