During low mains voltage or a mains dropout, the drive continues until the DC-link voltage drops below the minimum stop level, which
corresponds typically to 15% below the lowest rated supply voltage of the drive. Power-up and full torque cannot be expected at mains
voltage lower than 10% below the lowest rated supply voltage of the drive.
The drive is suitable for use on a circuit capable of delivering up to 100 kA short-circuit current rating (SCCR) at 480/600 V.
Motor Output (U, V, W)
5.3
Output voltage
Output frequency in U/f mode (for AM motor)
Output frequency in VVC+ mode (for AM motor)
Output frequency in VVC+ mode (for PM motor)
Switching on output
Ramp times
Torque Characteristics
5.4
Starting torque (constant torque)
Overload torque (constant torque)
1) Percentage relates to the nominal current of the drive.
2) Once every 10 minutes.
Ambient Conditions
5.5
J8/J9 enclosure size
Vibration test (standard/ruggedized)
Relative humidity
Aggressive environment (IEC 60068-2-43) H
Aggressive gases (IEC 60721-3-3)
Test method according to IEC 60068-2-43
Ambient temperature (at SFAVM switching mode)
- with derating
- with full output power of typical EFF2 motors (up to 90% output
current)
- at full continuous FC output current
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
28
| Danfoss A/S © 2024.01
5%–95% (IEC 721-3-3; Class 3K3 (non-condensing) during opera-
S test
2
0–100% of supply voltage
0–500 Hz
0–200 Hz
0–400 Hz
Unlimited
0.01–3600 s
Maximum 150% for 60 s
Maximum 150% for 60 s
IP20/Chassis
Class Kd
Class 3C3
H S (10 days)
2
Maximum 55 °C (131 °F)
Maximum 50 °C (122 °F)
Maximum 45 °C (113 °F)
-15 °C (5 °F)
-20 °C (-4 °F)
-25 to +65/70 °C (13 to 149/158 °F)
