Design Guide | VLT® AutomationDrive FC 360
Table 45: Drive Status Word (FC Profile)
Coil
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
Table 46: Address/Registers
Bus address
Bus register
0 1
1 2
2 3
3 4
4 5
5 6
6 7
104
| Danfoss A/S © 2024.01
0
Control not ready
Drive not ready
Coast stop
No alarm
Not used
Not used
Not used
No warning
Not at reference
Hand-on mode
Out of frequency range
Stopped
Not used
No voltage warning
Not in current limit
No thermal warning
PLC register Content
(1)
40001 Reserved
40002 Reserved
40003 Reserved
40004 Free
40005 Free
40006 Modbus config-
uration
40007 Last fault code
1
Control ready
Drive ready
Safety closed
Alarm
Not used
Not used
Not used
Warning
At reference
Auto mode
In frequency range
Running
Not used
Voltage warning
Current limit
Thermal warning
Access Description
– Reserved for legacy frequency con-
verters VLT® 5000 and VLT® 2800.
– Reserved for legacy frequency con-
verters VLT® 5000 and VLT® 2800.
– Reserved for legacy frequency con-
verters VLT® 5000 and VLT® 2800.
– –
– –
Read/Write TCP only. Reserved for Modbus TCP
(parameter 12-28 Store Data Values
and parameter 12-29 Store Always -
stored in, for example, EEPROM).
Read only Fault code received from parameter
database, refer to WHAT 38295 for
details.
