Design Guide | VLT® AutomationDrive FC 360
Table 9: Terminal Descriptions (continued)
Terminal
20
Analog inputs/outputs
50
53
54
42
45
55
Serial communication
61
68(+)
69(-)
Relays
01, 02, 03
04, 05, 06
Fuses and Circuit Breakers
7.5
Fuses ensure that possible damage to the drive is limited to damages inside the unit. To ensure compliance with EN 50178, use the
recommended fuses as replacements. Use of fuses on the supply side is mandatory for IEC 60364 (CE) compliant installations.
Type aR fuses are recommended for enclosures J8–J9.
Table 10: J8–J9 Power/Semiconductor Fuse Sizes
Model
H90K/Q110
H110/Q132
H132/Q160
H160/Q200
56
| Danfoss A/S © 2024.01
Parameter
–
–
Parameter group 6-1* Analog Input 1
Parameter group 6-2* Analog Input 2
Parameter 6-91 Terminal 42 Analog
Output
Parameter 6-71 Terminal 45 Analog
Output
–
–
Parameter group 8-3* FC Port
Settings
Parameter group 8-3* FC Port
Settings
Parameter 5-40 Function Relay [0]
Parameter 5-40 Function Relay [1]
Default setting Description
– Common for digital inputs and 0 V
potential for 24 V supply.
+10 V DC 10 V DC analog supply voltage. 15
mA maximum commonly used for
potentiometer or thermistor.
Reference Analog input. Selectable for voltage
or current.
Feedback
[0] No operation Programmable analog output. The
analog signal is 0–20 mA or 4–20 mA
at a maximum of 500 Ω. Can also be
[0] No operation
configured as digital outputs.
– Common for analog input.
– Integrated RC-filter to connect cable
shield if there are EMC problems.
– RS485 interface. A switch is provided
on the control card for bus termina-
tion resistance.
–
[0] No operation Form C relay output. For AC or DC
voltage and resistive or inductive
[0] No operation
loads.
380–480 V
ar-315
ar-350
ar-400
ar-500
AJ435824192086en-000101 / 130R1295
