Digi XBee-PRO S2C Zigbee User Manual page 281

Part number Type (description)
A24-F3NF Omni-directional
(Fiberglass base
station)
A24-F5NF Omni-directional
(Fiberglass base
station)
A24-F8NF Omni-directional
(Fiberglass base
station)
A24-F9NF Omni-directional
(Fiberglass base
station)
A24-F10NF Omni-directional
(Fiberglass base
station)
A24-F12NF Omni-directional
(Fiberglass base
station)
A24-F15NF Omni-directional
(Fiberglass base
station)
A24-W7NF Omni-directional (Base
station)
A24-M7NF Omni-directional (Mag-
mount base station)
Gain Min.
Application
(dBi) 1 separation
3.0 Fixed/Mobile 20 cm
5.0 Fixed/Mobile 20 cm
8.0 Fixed 20 cm
9.5 Fixed 20 cm
10.0 Fixed 20 cm
12.0 Fixed 20 cm
15.0 Fixed 20 cm
7.2 Fixed 20 cm
7.2 Fixed 20 cm
Required cable-loss or Required cable-loss
power reduction from or power reduction
+8 dBm channels 11 to from +8 dBm
24 channel 25
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
Required cable-loss
or power reduction
from +1 dBm channel
26
0
0
0
1.5
2.5
4.5
7.5
0
0
