API Operation
Frame data fields
Start delimiter
Length
Frame type
Frame ID
64-bit destination address
Reserved
Remote command options
AT command
Command parameter
Checksum
XBee/XBee-PRO® S2C Zigbee® RF Module
Offset
Example
0
0x7E
MSB 1
0x00
LSB 2
0x10
3
0x17
4
0x01
MSB 5
0x00
6
0x13
7
0xA2
8
0x00
9
0x40
10
0x40
11
0x11
LSB 12
0x22
0xFF
13
0xFE
14
15
0x02 (apply changes)
16
0x42 (B)
17
0x48 (H)
18
0x01
19
0xF5
Frame descriptions
168
