Digi XBee-PRO S2C Zigbee User Manual page 162

API Operation
Frame data fields
RF data
Checksum
Send a transmission to the coordinator without specifying the coordinator's 64-bit address. The API
transmit request frame should look like:
0x7E 0x00 0x16 0x10 0x01 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0xFF
0xFE 0x00 0x00 0x54 0x78 032 0x43 0x6F 0x6F 0x72 0x64 0xFC
Where 0x16 = length (22 bytes excluding checksum)
Frame data fields
Start delimiter
Length
Frame type
Frame ID
64-bit destination
address
16-bit destination
network address
XBee/XBee-PRO® S2C Zigbee® RF Module
Offset Example
17 0x54
18 0x78
19 0x44
20 0x61
21 0x74
22 0x61
23 0x30
24 0x41
25 0x13
Offset
0
MSB 1
LSB 2
3
4
MSB 5
6
7
8
9
10
11
LSB 12
MSB 13
LSB 14
Frame descriptions
Example
0x7E
0x00
0x16
0x10
0x01
0x00
0x13
0xA2
0x00
0x40
0x0A
0x01
0x27
0xFF
0xFE
