Digi XBee-PRO S2C Zigbee User Manual page 275

Part number Type (description)
A24-F8NF Omni-directional (Fiberglass base station)
A24-F9NF Omni-directional (Fiberglass base station)
A24-F10NF Omni-directional (Fiberglass base station)
A24-F12NF Omni-directional (Fiberglass base station)
A24-W7NF Omni-directional (Fiberglass base station)
A24-M7NF Omni-directional (Mag-mount base station)
A24-F15NF Omni-directional (Fiberglass base station)
Panel antennas
A24-P8SF Flat Panel
A24-P8NF Flat Panel
A24-P13NF Flat Panel
A24-P14NF Flat Panel
A24-P15NF Flat Panel
A24-P16NF Flat Panel
A24-P19NF Flat Panel
Yagi antennas
A24-Y6NF Yagi (6-element)
A24-Y7NF Yagi (7-element)
A24-Y9NF Yagi (9-element)
Gain
Min
(dBi)
Application* separation
8.0 Fixed 2 m
9.5 Fixed 2 m
10 Fixed 2 m
12 Fixed 2 m
7.2 Fixed 2 m
7.2 Fixed 2 m
15.0 Fixed 2 m
8.5 Fixed 2 m
8.5 Fixed 2 m
13.0 Fixed 2 m
14.0 Fixed 2 m
15.0 Fixed 2 m
16.0 Fixed 2 m
19.0 Fixed 2 m
8.8 Fixed 2 m
9.0 Fixed 2 m
10.0 Fixed 2 m
Required antenna cable loss
(dB)
Channels 11-
25 Channel 26
N/A 1.3
N/A 2.8
N/A 3.3
N/A 5.3
N/A .5
N/A .5
1.1 8.3
2.8 4.5
2.8 4.5
7.3 9.0
8.3 10.0
9.3 11.0
10.3 12.0
13.3 15.0
2.4 4.2
2.6 4.4
3.6 5.4
