6. Electronic Module
6.4.

Connections

Sensors for valve position detection:
Internal sensors:
Internal hall sensors:
External sensors:
Power
+
-
24V
=
PLC
DI
DI
DI
DI
DI
DI M
DO
DO
DO
DO M
Power
+
-
24V
=
PLC
DI
DI
DI
DI
DI
DI M
DO
DO
DO
DO M
internal linear sensor SPX FLOW type
switching distance acc. to SPX FLOW
specification
"magnetic hall sensor"
SPX FLOW UB 4.75 - 5.25 VDC
switching distance acc. to SPX FLOW
specification
inductive proximity switch
SPX FLOW UB 4.75-5.25 VDC
switching distance acc. to SPX FLOW
specification
Negative Ground
PNP
Power+
1
Power-
2
DO Valve closed
3
DO Valve open
4
DO upper lift
5
DO Lower lift
6
DO Service
7
DI Main Valve
8
DI Upper lift
9
DI Lower lift
10
11
5V DC
12
Sensor 2
13
GND
Sensor 1
Positive Ground
NPN
Power+
1
Power-
2
DO Valve closed
3
DO Valve open
4
DO upper lift
5
DO Lower lift
6
DO Service
7
DI Main Valve
8
DI Upper lift
9
DI Lower lift
10
11
5V DC
12
Sensor 2
13
GND
Sensor 1
