6. Electronic Module
6.2. Functional description of connections
Designation Functional Description
Power+
power supply 24VDC+
Power-
power supply 24VDC-
O0 Digital Output
PLC input valve status / closed
O1 Digital Output
PLC input valve status / open
O2 Digital Output
PLC input valve status / upper seat lift
O3 Digital Output
PLC input valve status / lower seat lift
SV Digital Output
PLC input service request
I0 Digital Input
PLC output to activate solenoid 1 / main valve
I1 Digital Input
PLC output to activate solenoid 2 / upper seat lift
I2 Digital Input
PLC output to activate solenoid 2 / lower seat lift
+5VDC
supply voltage for SPX prox. sensor / linear sensor
S
signal SPX prox. sensor
0V
potential for SPX prox. sensor / linear sensor
PWM Output
solenoid valve 1 (main valve)
PWM Output
solenoid valve 2 (upper seat lift)
PWM Output
solenoid valve 3 (lower seat lift)
connection serial/USB converter for CU4plus toolbox
