Six-position, 5-way - pump mounted manual dual valve assembly

Advertisement

SPX Corporation
5885 11th Street
Rockford, IL 61109-3699 USA
Internet Address:
http://www.powerteam.com
IMPORTANT: To help prevent possible equipment damage, check the operating pressures of your tool. If the
pressures are different from the specifications in this chart, contact Power Team Technical Services
Department.
This valve is designed to be used with pumps that have a 10,000 PSI maximum operating pressure.
WARNING
● ●
All WARNING statements must be carefully observed to help prevent personal injury.
● ●
Before operating the pump, all hose connections must be tightened with proper tools. Do not overtighten.
Connections need only be tightened securely and leak-free. Overtightening may cause premature thread
failure or may cause high pressure fittings to split at pressures lower that their rated capacities.
● ●
Should a hydraulic hose ever rupture, burst, or need to be disconnected, immediately shut off the pump
and shift the control valve twice to release all pressure. Never attempt to grasp a leaking hose under
pressure with your hands. The force of escaping hydraulic fluid could cause serious injury.
● ●
Do not subject the hose to potential hazard such as fire, extreme heat or cold, sharp surfaces, or heavy
impact. Do not allow the hose to kink, twist, curl, or bend so tightly that the oil flow within the hose is
blocked or reduced. Periodically inspect the hose for wear because any of these conditions can damage
the hose and possibly result in personal injury.
● ●
Do not use the hose to move attached equipment. Stress may damage the hose and possibly cause
personal injury.
● ●
Hose material and coupler seals must be compatible with the hydraulic fluid used. Hoses also must not
come in contact with corrosive materials such as creosote-impregnated objects and some paints. Consult
the manufacturer before painting a hose. Never paint the couplers. Hose deterioration due to corrosive
materials may result in personal injury.
© SPX Corporation
Tech. Services: (800) 477-8326
Fax: (800) 765-8326
Order Entry: (800) 541-1418
Fax: (800) 288-7031
SIX-POSITION, 5-WAY - PUMP MOUNTED
MANUAL DUAL VALVE ASSEMBLY
Max. Capacity: Valve "A" = 10,000 PSI

SPECIFICATIONS

Max. Pressure
Max. Return & Seat
Pressure
Max. Flow Rating
Max. Valve Case
(Tank Line Pressure)
Port Sizes

DESCRIPTION

SAFETY PRECAUTIONS

®
Operating Instructions for:
Valve "B" = 6,000 PSI
Valve "A"
Valve "B"
10,000 PSI
6,000 PSI
6,000 PSI
6,000 PSI
5 GPM
5GPM
500 PSI
500 PSI
3/8 NPTF
3/8 NPTF
Form No. 102639
Sheet No.
1 of 1
Issue Date:
7-1-91
