6.

Cleaning

6.1. Cleaning recommendation
The valve passage is cleaned by the cleaning liquids during
cleaning of the connected pipelines.
Depending on the degree and constituents of soiling, the cleaning
liquids, times and processes must be scheduled for the individual
application.
The compatibility of the individually selected cleaning processes
and liquids with the respectively used seals must be verified.
7. Installation / Connections
In normal installation position, the actuator is positioned vertically
to the top. Depending on the respective application, optional
installation positions can, however, also be realized.
SV1 valves with weld ends are welded direct into the product
line.
Separate dismantling by a flange connection, etc. in the continuing
pipeline must be provided.
Attention: Observe welding instructions 7.2.
7.1.

Connections:

Beside the housings with weld ends the following connections
are alternatively available:
- threaded and cone port to DIN 11851,
- threaded port RJT, ISS/IDF, SMS.
- clamp connection to 32676 (DN 25 - 100)
- clamp connection to ISO 2852 (Inch 1" - 4")
