I N S T R U C T I O N M A N U A L
APV UFMS4
A S E P T I C P R E S S U R E R E L I E F VA LV E
F O R M N O . : H 3 4 7 0 2 6
R E V I S I O N : G B - 0
R E A D A N D U N D E R S TA N D T H I S M A N U A L P R I O R TO O P E R AT I N G O R S E RV I C I N G T H I S P R O D U C T.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APV UFMS4 and is the answer not in the manual?

Questions and answers

Related Manuals for SPX FLOW APV UFMS4

Summary of Contents for SPX FLOW APV UFMS4

  • Page 1 I N S T R U C T I O N M A N U A L APV UFMS4 A S E P T I C P R E S S U R E R E L I E F VA LV E F O R M N O .

  • Page 4: Table Of Contents

    Maintenance of actuator 12.2. Installation of seals and assembly of actuator Assembly Tool 13.1. Installation of seat seal in valve shaft Trouble Shooting Spare Parts Lists UFMS4 DN & Inch RN 01.064.11 Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 5: General Terms

    SPX FLOW company for their professional disposal and free of charge for you. Please address to your local SPX FLOW company. Never touch the valve or pipelines during hot liquid processes! Do not touch the open valve or yoke! Risk of injury by sudden valve operation.

  • Page 6: Safety

    Note! SPX FLOW APV Valves (without safety function) are allocated to Category 1 and are evaluated as per Conformity Assessment Module A of the Pressure Equipment Directive 2014/68/EU.

  • Page 7: Mode Of Operation

    Intended Use Caution! The standard UFMS4 valve must not be used in explosive atmospheres. SPX FLOW APV Valves are intended for use in the food and beverage industries, as well as in pharmaceutical and chemical applications. Authorizations and External Approvals...

  • Page 8: Auxiliary Equipment

    For the valve position indication, proximity switches can be installed in the yoke area. If the customer decides to use valve position indicators other than those listed above, SPX FLOW cannot assume any liability for the functionality of the valve. 5.2.

  • Page 9: Control Unit

    (see chapter 6.) 5.4. Housing configurations Different housing shapes can be applied to reduce dead spaces to a minimum. fig. 5.3. fig. 5.4. UFMS 41 UFMS 42 actuator UFMSE 41 UFMSE 42 UFMSE 43 UFMSE 44 air connection for seat lifting Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 10: Cleaning

    Depending on the degree and contents of soiling, the cleaning liquids, times and processes for the individual application must be scheduled. Caution! The cleaning liquid applied must be compatible with the respective seal material. Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 11: Installation And Commissioning

    If these welding instructions are not followed, any resulting damage will not be covered by the warranty. Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 12: Dimensions And Weights

    10,8 4" 97,6 10,2 10,8 4" 97,6 17,1 17,7 * Min. response pressure is depending on the installation position and friction > 0, ** Without/With Control Unit, *** Without/With Control Unit Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 13: Technical Data

    Content of oil: quality class 1, max. 0,01 mg/m³ The oil applied must be compatible with Polyurethane elastomer materials. Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...
  • Page 14 2,0 - 6,6 6,1 - 10 DN80 0 - 0,9 0,4 - 1,8 1,6 - 5,2 4,7 - 10 DN100/4" 0 - 0,6 0,2 - 1,2 1,0 - 3,5 3,0 - 10 Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 15: Valve Stroke / Opening Cross Section

    APV_UFMS4_GB-0_112024.indd Technical Data 9.6. Valve stroke / Opening cross section (X) Dimensions in mm Stroke 22,5 19,5 Inch 1" 1,5" 2" 2,5" 3" 4" Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 16: Maintenance

    Caution! Do not clean the valve with products containing abrasive or polishing substances. For valve maintenance SPX FLOW offers complete seal kits (see spare parts lists). Dismantling and installation of seals acc.to Service Instructions. Assembly and adjustment of actuator according to Service Instructions.

  • Page 17: Service Instructions

    6. Unscrew the yoke (9) from the actuator (17). Note! The actuator can be maintained. See chapter 12. Service Instructions for Actuator. 7. Detach the O-Ring (13) and guide bushing (11). Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 18: Installation Of Seals And Assembly Of Valve

    Loctite, semi-solid, on the thread of the guide rod. Screw on the hex. nut (22) and fasten it. Hold up the centering washer during this process. o-ring diaphragm Tightening torque: 40 Nm. guide rod lower shaft seat seal Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 19: Installation Of Valve

    12. Place the actuator in the closed limit position and carry out positioning of the second proximity switch. positioning screw o-ring feedback cam hex nut centering washer guide rod hex. screw M8 Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 20: Service Instructions For Actuator

    Note! The connecting rod must move smoothly without friction in O-ring (12.5) the bushing. V-seal (12.4) seal screw 5. Fasten the air hose. (12.3) detail seal screw: O-ring (12.5) V-seal (12.4) Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 21: Assembly Tool

    000 51-13-110/17 H179465 1,5" 000 51-13-111/17 H179466 2" 000 51-13-112/17 H179467 threaded bolt 2,5" 000 51-13-12017 H179468 000 51-13-113/17 H179469 3" 000 51-13-121/17 H179470 000 51-13-114/17 H179471 4" 000 51-13-115/17 H179472 Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 22: Trouble Shooting

    Seat lifting does not work Replace complete actuator (12). (air escapes permanently from the vent bore). Do not open cylinder by force. Spring force! Valve position indication No feedback. Carry out fine adjustment. Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...

  • Page 23: Spare Parts Lists

    Please indicate the following data to place an order for spare parts: - number of required parts - reference number - designation Data are subject to change. Aseptic Pressure Relief Valve APV UFMS4 Instruction Manual: GB-0...
  • Page 24 F: (+48) 52 525 99 09 SPX FLOW reserves the right to incorporate the latest design and material changes without notice or obligation. Design features, materials of construction and dimensional data, as described in this manual, are provided for your information only and should not be relied upon unless confirmed in writing.
