Installation
l'installation / Installation / Installazione / Instalación / Installatie /
Installasjon / Telepítés / Instalace / inštalácia / Instalacja / Montaj / Монтаж
Always ensure the filling loop is fitted after the filter.
o potrubí.
na
сто
1
22mm Compression
Cut and remove section.
22mm Compression
1
Tighten
compression
nuts.
1
CAUTION:
Do NOT
overtighten.
2
22mm Compression
2
1" BSP
Ensure that wall clips are used to attach pipework to the wall,
as close as possible to valves 'A' and 'B'.
22mm Compression
1
Valve A
2
1
2
Valve B
3
Use tool provided
to ensure pipework
is aligned & ready for
canister installation.
CAUTION: Ensure there
is no resistance when
removing alignment tool.
9
