- Page 1 MagnaClean CMX ® MIDI PRO ASSIST & MIDI PRO Sidestream Monitored Filtration Installation and servicing Commercial ®...
-
Page 2: Table Of Contents
Contents Checklist Location Key Features Unit Installation Electrical Installation/Earthing Controller Wiring Diagrams Operation Controller Programming Parameters Filtration & Pressure Differential Monitoring Flow & Temperature Measurement Maintenance & Servicing Environment Protection Technical Specification Troubleshooting Guide UK Declaration of Conformity Product Description Heating &... -
Page 3: Checklist
The pump is not accessible in normal operation mode. The unit must be operated with the front cover in place. This appliance must not be used for any other application without the written consent of ADEY Commercial Limited. This appliance can be used by children aged from 8 years and above and persons with... -
Page 4: Location
Automatic Air Vent (1”) & Valve Grundfos DPS Diff. Pressure Sensor Grundfos VFS Flow & Temp Sensor 28mm Compression Ball Valves ¼” Male - ½” Female Adaptor ADEY DEK1002 Modbus Controller 50-Micron Filter Cartridges LED Warning Light Fig. 2 2. Location Location: These sidestream skid units should be installed on a solid, level floor which is able to support the filled weight of the unit of c.41-44kg, dependent on the model being installed. -
Page 5: Key Features
5. ADEY DEK1002 Modbus Controller: The integrated controller supports Modbus BMS & sensor connectivity and monitoring capability, with programmable warnings & alarms such as high/low flow and high/low system water temperature;... -
Page 6: Unit Installation
MagnaClean CMX Midi Pro Assist (FL1-03-06632) The MagnaClean CMX Midi Pro Assist sidestream skid unit should be installed by a competent plumber or service engineer on a solid, level floor which is able to support the filled weight of the unit of c.44kg. - Page 7 4. Unit Installation MagnaClean CMX Midi Pro (FL1-03-06631) The MagnaClean CMX Midi Pro sidestream skid unit should be installed by a competent plumber or service engineer on a solid, level floor which is able to support the filled weight of the unit of c.41kg. Please ensure the minimum clearance requirements detailed in Fig.3 on page 5 are followed to allow for servicing of the unit.
-
Page 8: Electrical Installation/Earthing
4. Unit Installation (Cont.) IMPORTANT: Whilst the MagnaClean CMX Midi filters attached to these units carry a min/max temperature rating of -10⁰C to +150⁰C, when installed and used as an integral part of the CMX Midi Pro & CMX Midi Pro Assist sidestream units as they are, the MagnaClean CMX Midi filter min/max temperature rating is +2⁰C to +100⁰C only. - Page 9 If the supply cord is to be changed or is damaged, it must be replaced with a special cord assembly available from ADEY or one of their approved repairers. On disassembly note the cord retention and routing system. Re-assemble to the same pattern.
-
Page 10: Controller Wiring Diagrams
6. Controller Wiring Diagram MagnaClean CMX Midi Pro Assist (FL1-03-06632) Fig. 6 Controller Wiring Diagram MagnaClean CMX Midi Pro (FL1-03-06631) Fig. 7... -
Page 11: Operation
7. Operation Controller Overview: The unit controller is designed to be intuitive to use and allows functions and alarms to be set by the installer/user. It also allows faults to be monitored and logged to enable easier system fault diagnosis. The functions are set using the 4 buttons on the front of the controller, as per below in Fig. -
Page 12: Controller Programming Parameters
Once the Minutes value is adjusted, hold the SET button to save all Day. Month, Year, Hour & Minutes settings. 2. The controller will then scroll, ‘ADEY MagnaClean CMX Monitored Filtration v1.0’ followed by a unit status message: a) In normal operation with system monitoring and pump running, the display will scroll, ‘Pump Running’, ‘Unit Filtering’. - Page 13 PARAMETER PROGRAMMING MODE - ENGINEERS PARAMETER MENU (Code: 315) Parameter Description Default Range Service Date Adjust future service date: Day/Month/Year. Press & hold ‘SET to cycle across values. Will pass onto next parameter once complete Last Service Date Automatically updates when a new service date has been entered and will be visible next time user accesses parameters Cartridge*...
- Page 14 *NOTE: PARAMETER 1: - If Parameter 1 “Cartridge Present” is set to “YES”, Parameters 2 & 3 are not activated. - If Parameter 1 “Cartridge Present” is set to “NO”, Parameters 2 & 3 are activated and the timer will be active from that point. **NOTE: PARAMETER 2: - Parameter 2 “Magnet Only Service Warning”...
- Page 15 PARAMETER PROGRAMMING MODE - DATA LOGGING MENU (Code: 111) Parameter Description Default Range Last Service Date Automatically updates when a new service date has been entered and will be visible next time the user accesses parameters Service Date Automatically updates when a new service date has been entered DL3 Pump Hours Total pump operation time (Auto-Update)
- Page 16 ADEY DEK1002 MODBUS PROTOCOL - VARIABLE LIST DEFAULT SETTINGS BAUD RATE 9600 WORD LENGTH PARITY STOP BITS X Variable Denomination Type X Variable Data Conversion Units Equivalent Range of Notes Address Format Range X Variable 40001 Cartridge Present read/write word 16 bits 4 = No 5 = Yes 4->6...
- Page 17 X Variable Denomination Type X Variable Data Conversion Units Equivalent Range of Notes Address Format Range X Variable 40028 Parameter Pump Hours read/write word 16 bits Value = X Days 0-9999 0-9999 NOTE 2 40029 Current Water Flow read word 16 bits Value = X l/min 0->200...
- Page 18 Warning Conditions for Trigger Scrolled Message “Auto Reset” “Action on Outputs” Pump Fail Current Sense Pump Fail Pump – OFF Parameter = Y Buzzer – ON Pump Activated LED Light – ON Current level below Common Alarm – ON 125mA Service Filter Service Actual date beyond...
-
Page 19: Filtration & Pressure Differential Monitoring
However, there is no right or wrong way to configure the CMX Midi filter, which can be configured with cartridge filters immediately if that is what you believe the system requires. Please contact ADEY Customer Services on +44 (0)1242 546717 if you have any queries. -
Page 20: Flow & Temperature Measurement
100% of the system water volume should have passed through the sidestream filter within a 24-hour period. The MagnaClean CMX Midi Pro Assist & MagnaClean CMX Midi Pro units are designed for use on systems up to 93,000 litres in size. -
Page 21: Maintenance & Servicing
11. Maintenance – MagnaClean CMX Midi Filter Servicing of the CMX Midi filter should be carried out by a qualified plumber or service engineer. 1. Turn off the power to the unit via 2. Close both isolation valves at the 3. - Page 22 11. Maintenance – MagnaClean CMX Midi Filter (Cont.) 10. Replace lid, ensuring that the lid 11. Ensure filter drain port valve(s) 12. Turn the power to the unit back gasket is positioned and installed are closed and then open both on via the unit power switch.
-
Page 23: Environment Protection
Before dismantling the pump, drain the please contact ADEY Customer Services on system and close the isolating valves on +44 (0)1242 546717. the unit. -
Page 24: Technical Specification
13. Technical Specification MagnaClean CMX Midi Pro Assist (FL1-03-06632) MAGNACLEAN CMX MIDI PRO ASSIST Product code FL1-03-06632 General Guarantee 2 years Approvals UKCA Features Filter capacity Up to 93,000 litres Mounting type Floor mounted Unit controller DEK1002 Modbus (RS485) Controller... - Page 25 13. Technical Specification MagnaClean CMX Midi Pro (FL1-03-06631) MAGNACLEAN CMX MIDI PRO Product code FL1-03-06631 General Guarantee 2 years Approvals UKCA Features Filter capacity Up to 93,000 litres Mounting type Floor mounted Unit controller DEK1002 Modbus (RS485) Controller Construction Cabinet Powder-Coated Mild Steel MagnaClean CMX Midi Filter Polished 316L Stainless Steel...
-
Page 26: Troubleshooting Guide
Service filter & input new service interval date Pump is blocked with Unblock the pump and remove impurities impurities Pump is defective Replace pump - contact ADEY Customer Services PUMP RUNS AT MAX No signal from signal Check cable is connected to pump &... - Page 27 Supply voltage Warning only - Control the • • too low Pump runs supply voltage Electrical error Pump stopped due Control the supply to low supply voltage voltage. Replace the • • or serious failure pump - contact ADEY Customer Services...
-
Page 28: Declaration Of Conformity
EN 60529-1 Technical documentation is kept at the following address: ADEY Commercial Limited, UK Head Office, Unit 2, St. Modwen Park, Stonehouse, GL10 3EZ This declaration of conformity is issued under the sole responsibility of the manufacturer. SIGNED FOR AND ON BEHALF OF ADEY Commercial Limited... - Page 32 ADEY Commercial Ltd, Unit 2, St. Modwen Park, Stonehouse, GL10 3EZ Produced from recycled material A carbon neutral company All ADEY marks are trademarks of Adey Holdings (2008) Limited. Please visit adey.com/trademarks for a list of ADEY marks Copyright Adey Holdings (2008) Limited © 2022. All rights reserved.
