Replace drain plug.
Remove lid assembly.
Remove sleeve.
Clean
Dose with MC1+ Protector
O ring
The lid seal should be cleaned and checked for
wear when servicing MagnaClean. It is Best
Practice to replace the lid and drain valve seals
at each service.
"Only use Silicon grease or water to lubricate
O ring.
Do not use flux or EP grease."
Turn locking pin 90° and remove.
CAUTION: Ensure valves are off
Disconnect.
Remove.
CAUTION: Clean and inspect collets and
lubricate seals with water only.
Fit quick release trigger and canister onto
valves.
CAUTION: Ensure canister is firmly pushed onto
valves until fully engaged.
Replace locking pin and turn 90° to lock
Zamocuj korek spustowy.
Odkręć zespół pokrywy.
Zdejmij tuleję.
Wyczyść
Wlej preparat MC1+.
Uszczelka
Podczas serwisowania systemu MagnaClean
wyczyść uszczelkę pokrywy i sprawdź, czy nie
nosi śladów zużycia. Najlepiej jest wymienić
pokrywę i uszczelki zaworów spustowych przy
każdym serwisowaniu.
"Użyj wyłącznie smaru silikonowego lub wody do
posmarowania uszczelki.
Nie stosuj smaru stałego ani smaru EP."
Przekręć przetyczkę blokującą o 90° i wyjmij ją.
UWAGA: zawory muszą być zamknięte.
Odłącz.
Zdejmij.
UWAGA: wyczyść i sprawdź uszczelki zaciskowe;
pozostałe uszczelki posmaruj wyłącznie wodą.
Zamontuj spust szybkiego odblokowania i
zbiornik na zaworach.
UWAGA: mocno dociśnij zbiornik do zaworów,
aż się zatrzaśnie.
Wsuń przetyczkę blokującą i przekręć ją o 90°.
35
