Summary of Contents for Adey MagnaClean Professional3 Sense
- Page 1 Installation and servicing...
- Page 2 IMPORTANT Always follow the Standard Electrical Best Practice guidelines when installing a MagnaClean filter. A copy of these can be found at http://www.hse.gov.uk/electricity For the most up to date version of the MagnaClean Professional3 Sense Installation and Servicing instructions visit adey.com. Warranty Terms & Conditions can be found at adey.com...
-
Page 3: Technical Specification
Technical specification Operating Parameters: Internal water operating temperature: 3°C to 95°C Internal operating water pressure: Up to 6 bar Recommended ambient room temperature: 3°C to 40°C Maximum flow rate: 50L/min Flow direction: Bi-directional Fluid capacity: 0.55 litres Inlet: 22mm compression at valve Outlet: 22mm compression at valve Electronic sub-assembly: Enclosure rated to IP52 specification... -
Page 4: Installation Overview
It is recommended that the filter is installed by a qualified heating engineer. Installation overview MagnaClean Professional3 Sense can be installed anywhere before the boiler. To achieve the best level of protection, it is recommended that the filter is fitted after the last radiator and before the boiler. - Page 5 App Manage all your connected devices via the “Sense App” and “Sense Portal” Your Subscription Results can be viewed and managed in the ADEY Sense App and ADEY Sense portal (subject to subscription). To access the portal visit: sense.adey.com ®...
- Page 6 ADEY Sense ® MagnaClean Professional3 Sense Dashboard Overview: Company account If you are name connected to more than one ADEY Sense account, switch between them here Main dashboard displays total properties on account and latest alert status. Swiping left will sort...
- Page 7 Pro3-1597634 MENU Latest product Enables easy status reported navigation of App. Informs how the Sub menu includes: filter is performing, • Filter reset including • Remove filter recommended from account courses of action • Factory reset where appropriate Magnetite Capture Gauge Green = Magnetite capture level is low...
- Page 8 Sense dashboard via the home Wi-Fi. You can view the live status on your smartphone, computer or tablet. PLEASE NOTE: Connect your filter to your ADEY Sense account first before installing onto the heating system. The filter should be installed so that it can communicate wirelessly with the router (up to a maximum distance of 30m).
-
Page 9: Quick Setup
All (GREEN) LEDs will illuminate for 2 seconds replaced. then go off. Step 2. Connect your Filter to the Wi-Fi network (Note: Use only in conjunction with the ADEY Sense App). Initiate Connection Mode LED OPERATION Press and hold Check Button for 6 seconds, All (GREEN) LEDs will flash twice as soon as this will initiate “Connection Mode”. - Page 10 Cut and remove section using measurement guide sticker supplied. Your customer’s warranty registration is now complete. Your ADEY ProClub loyalty points will automatically Register filter according be added to your account to instructions in App. (subject to T&Cs). Ensure that wall clips...
- Page 11 SHEET GL51 8NR DRAWN DATE ECR No. CHECKED THIS DRAWING REMAINS THE PROPERTY OF ADEY INNOVATION LTD. AND MUST NOT BE COPIED OR WEIGHT grams (est.) 0.XX - ±0.1 ANGULAR ±0.1° SCALE PASSED TO A THIRD PARTY WITHOUT PERMISSION TEL: +44 (0) 01242 546 700 Email: info@adey.com...
- Page 12 Servicing 1 - Turn valves off. Isolate boiler mains ✗ 2 - Vent. power supply. Remove drain plug Turn power off. Vent. Replace drain plug. Important - Do NOT overtighten. Remove lid assembly Clean Clean Clean Remove sleeve.
- Page 13 CHECKED WEIGHT 0.XX - ±0.1 SCALE THIS DRAWING REMAINS THE PROPERTY OF ADEY INNOVATION LTD. AND MUST NOT BE COPIED OR grams (est.) ANGULAR ±0.1° PASSED TO A THIRD PARTY WITHOUT PERMISSION TEL: +44 (0) 01242 546 700 Email: info@adey.com...
- Page 14 Quick-release trigger MagnaClean Professional3 Sense incorporates a secure, quick-release, trigger which enables the filter to be removed and re-installed in seconds. The connections enable easy and swift filter removal during annual servicing or to undertake a MagnaCleanse system flush. This also makes it ideal for systems where there is little room to install a filter.
-
Page 15: Retro-Fit Installation
Retro-Fit Installation - Upgrade a MagnaClean Professional2 to a MagnaClean ® Professional3 Sense using the simple instructions below: Isolate boiler mains 1 - Turn valves off. ✗ power supply. 2 - Vent. Turn power off. Open drain valve to release water. Fully unlock red wheel from canister. - Page 16 LED Flash pattern Glossary 1. Manual reading of magnetite levels inside the filter Manual Reading LED OPERATION Single press of Check Button then release. All 4 x LEDs will illuminate in sequential order (left to right). Only relevant LEDs will remain lit for a short period to represent magnetite level in filter. A clean filter will show 1 (Green) LED.
- Page 17 LED Flash pattern Glossary (cont.) 5. Critically Low Battery Change Batteries Immediately LED OPERATION Single press of Check Button then release. If critically low battery - solid (RED) LED will illuminate for 2 seconds indicating batteries need replacing. (GREEN) LEDs will not show magnetite reading. 6.
-
Page 18: Frequently Asked Questions
The homeowner’s system details are stored within the App and can be referenced at any time prior to attending an onsite visit. ADEY does not share user data with a third party. This is in line with ADEY’s data privacy policy which can be found here: https://www.adey.com/privacy-policy... - Page 20 Email: info@adey.com adey.com Produced from recycled material A carbon neutral company All ADEY marks are trademarks of Adey Holdings (2008) Limited. Please visit adey.com/trademarks for a list of ADEY marks Copyright Adey Holdings (2008) Limited © 2022. All rights reserved.
