Instruction Manual (D)
for Turbomolecular Pump
Applicable pump model
Read through the Safety Precautions and
each section of this Manual carefully before
using the STC-U.
Keep this Manual in a place where you can
quickly access it at any time.
Read this Manual thoroughly and keep it with
the Turbomolecular Pump Instruction Manual.
STP pump consists of the four-volumed Instruction Manuals.
Instruction Manual (A):
Instruction Manual (B):
Instruction Manual (C):
Instruction Manual (D):
(This Instruction Manual)
STC-U eTMS unit
◼ STP-XF803/XF1303 series
STP pump generic Instruction Manual
STP pump specific information
STP control unit Instruction Manual
STC-U eTMS unit for Turbomolecular Pump
Copyright 2023 Edwards Japan Limited. All rights reserved. Printed in Japan.
MT-92E-A01-C
2023.08
