- Page 1 2023-12 New as of: inEos X5 Operating Instructions English...
-
Page 2: Table Of Contents
Blue light radiation (UV) ....................To be taken into account during automatic operation ..........Intended use........................ Technical description..................Design and function..................... System components....................4.2.1 Components of the inEos X5 ................ Technical data ......................Certification ......................... System requirements ....................Electromagnetic compatibility..................Electromagnetic emission ................4.6.1 4.6.2... - Page 3 Connecting the foot switch (optional)............6.3.4 Switching the unit on and starting the software ..........Calibrating the motor arm.................... Calibrating the inEos X5 camera................. Updating the firmware ....................Controls and displays ..................Controls on the inEos X5..................... Operating state LED....................
- Page 4 Table of contents Dentsply Sirona Operating Instructions inEos X5 Free scans........................9.3.1 Preparing the optical impression..............9.3.2 Automatic and manual release in the "free scan" mode ....... 9.3.3 Taking a free scan (without previous automatic scans) ........ 9.3.4 Taking a free detail scan................
-
Page 5: Dear Customer
1 Dear Customer, Operating Instructions inEos X5 Dear Customer, ® Thank you for purchasing your inEos X5 from Sirona. Improper use and handling can create hazards and cause damage. Please read and follow these operating instructions carefully and Always keep them within easy reach. -
Page 6: General Data
2 General data Dentsply Sirona 2.1 Contact information Operating Instructions inEos X5 General data Please read this document completely and follow the instructions exactly. You should always keep it within reach. Original language of the present document: German. Contact information... -
Page 7: Formats And Symbols Used
Dentsply Sirona 2 General data Operating Instructions inEos X5 2.3 Legend 2.2.2 Formats and symbols used The formats and symbols used in this document have the following meaning: Prerequisite Identifies an action sequence with prompt and result. 1. First action step 2. - Page 8 2 General data Dentsply Sirona 2.3 Legend Operating Instructions inEos X5 Symbols on the packaging Take note of the following symbols on the packaging: Keep dry Fragile; handle with care Stack limit Temperature during storage and transport Relative humidity during storage and transport...
-
Page 9: Safety
Maintenance and repair ● The maintenance and repair of this unit may be performed only by Dentsply Sirona or by agencies authorized by Dentsply Sirona. ● Components which have failed and influence the safety of the unit must be replaced with original (OEM) spare parts. -
Page 10: Modifications To The Product
In order to ensure product safety, this device may be operated only with original Dentsply Sirona accessories or third-party accessories expressly approved by Dentsply Sirona. In particular, only the power cable also supplied or the corresponding original spare part may be used with the unit. -
Page 11: Blue Light Radiation (Uv)
Risk of injury for those diagnosed with epilepsy For persons who have been diagnosed with epilepsy, there is a risk of epileptic shock through the flashing light of the inEos X5. ➢ Patients who have been diagnosed with epilepsy must not work with the inEos X5. -
Page 12: To Be Taken Into Account During Automatic Operation
3 Safety Dentsply Sirona 3.3 To be taken into account during automatic operation Operating Instructions inEos X5 To be taken into account during automatic operation CAUTION Risk of injury! / collision hazard! During automatic operation there is a risk of injury/collision hazard as a result of the swiveling movement of the articulated arm. -
Page 13: Technical Description
4.1 Design and function Technical description Design and function The inEos X5 is designed as a desktop unit and consists of several components (see Chapter "System components [→ 13]“). It is powered from the standard local power network via an external power supply unit. - Page 14 4 Technical description Dentsply Sirona 4.2 System components Operating Instructions inEos X5 Rear side 24 V M6324649 S00106 Model-No. D3586 Merial-No. 00106 6324649 2013 24 V / 120 W Sirona Dental Systems GmbH Fabrikstr. 31 D-64625 Bensheim Made in Germany...
-
Page 15: Technical Data
Dentsply Sirona 4 Technical description Operating Instructions inEos X5 4.3 Technical data Technical data Model designation inEos X5 Power connection Via power supply unit: INPUT: 100 - 240 V AC / 47- 63 Hz / 2.0 A max. Permissible line voltage fluctuations: ±... -
Page 16: Certification
Electromagnetic compatibility Observance of the following information is necessary to ensure safe operation regarding EMC aspects. inEos X5 complies with the requirements for electromagnetic compatibility (EMC) according to DIN EN 61326-1:2006-10. inEos X5 is hereinafter referred to as "UNIT". 64 17 096 D3586... -
Page 17: Electromagnetic Emission
Dentsply Sirona 4 Technical description Operating Instructions inEos X5 4.6 Electromagnetic compatibility 4.6.1 Electromagnetic emission The UNIT is intended for operation in the electromagnetic environment specified below. The customer or user of the UNIT should make sure that it is used in such an environment. -
Page 18: Immunity To Interference
4 Technical description Dentsply Sirona 4.6 Electromagnetic compatibility Operating Instructions inEos X5 4.6.2 Immunity to interference The UNIT is intended for operation in the electromagnetic environment specified below. The customer or user of the UNIT should make sure that it is used in such an environment. - Page 19 Dentsply Sirona 4 Technical description Operating Instructions inEos X5 4.6 Electromagnetic compatibility Interference immu- DIN EN 61326-1 Test Compliance level Electromagnetic environment – nity tests level guidelines Conducted RF in- d= [1.2] √P terference 150 kHz to 80 MHz IEC 61000-4-6...
-
Page 20: Working Clearances
4 Technical description Dentsply Sirona 4.6 Electromagnetic compatibility Operating Instructions inEos X5 4.6.3 Working clearances Recommended working clearances The UNIT is intended for operation in an electromagnetic environment, between portable and mobile RF where radiated RF interference is checked. The customer or the user of... -
Page 21: Transport To The Installation Site
5.1 Transport and unpacking Transport to the installation site Transport and unpacking All Dentsply Sirona units are carefully checked prior to shipment. Please perform an incoming inspection immediately after delivery. 1. Check the delivery note to ensure that the consignment is complete. -
Page 22: Installation Site
Install inEos X5 in a protected area 3D image acquisition may be adversely affected by bright light. Set the inEos X5 up so that it is not located directly in the beam path of an extreme light source and not exposed to direct sunlight. -
Page 23: Initial Startup
Dentsply Sirona 6 Initial startup Operating Instructions inEos X5 6.1 Putting inLab PC into operation Initial startup Putting inLab PC into operation 6.1.1 Startup prerequisites 6.1.1.1 Required accessories Supplied parts: ● inLab PC with power cable ● Keyboard ● Mouse ●... -
Page 24: Making Connections
6.1.1.2 Making connections NOTICE Do not connect or switch on the inEos X5 yet! First, connect the PC to the monitor, keyboard, and mouse. Follow the instructions in this document exactly in order to successfully perform start-up of your device. -
Page 25: Safety
Dentsply Sirona 6 Initial startup Operating Instructions inEos X5 6.1 Putting inLab PC into operation 6.1.2 Safety The inLab-PC V 5.0.1 is equipped with Windows 10. The Windows Firewall is activated. The software Microsoft Security Essentials is also pre-installed by default. Please activate the automatic update function in the settings of this software for optimal protection. -
Page 26: Installing The Software
Operating Instructions inEos X5 Installing the software NOTICE Initial installation without inEos X5 Perform the initial installation of the software without connecting inEos The software requires the 2.00 firmware version of the license stick. Update the firmware version if necessary. For additional information, refer to the "License manager"... -
Page 27: Connecting The Unit
Fabrikstr. 31 D-64625 Bensheim Made in Germany Socket for power supply ➢ Connect the socket (A) of the inEos X5 to the power supply via the power supply unit included in the scope of supply. NOTICE Use a grounded power outlet The power supply unit must be connected to a grounded power outlet. -
Page 28: Switching The Unit On And Starting The Software
Calibrating the motor arm IMPORTANT Calibrating the system Following installation of the inEos X5, it is recommended that you perform an axis calibration with the inLab SW software. ü The inEos X5 is switched on. ü The jaw model supplied for calibration is ready. -
Page 29: Calibrating The Ineos X5 Camera
Calibrating the inEos X5 camera IMPORTANT Calibrating the system The calibration of the inEos X5 camera is only required if you use ATLANTIS-FLO-S scanbodies in order to design single-piece directly screwed suprastructures and to have them manufactured at INFINIDENT SOLUTIONS or in order to transmit the scanned models to Dentsply-Sirona-ATLANTIS central manufacturing for design and manufacturing purposes. -
Page 30: Updating The Firmware
6.6 Updating the firmware Operating Instructions inEos X5 Updating the firmware In order to update the inEos X5 firmware, proceed as follows: 1. Click the "Devices" icon in the system menu. 2. Click on the icon of inEos X5. 3. Click on "Update Firmware" . -
Page 31: Controls And Displays
Dentsply Sirona 7 Controls and displays Operating Instructions inEos X5 7.1 Controls on the inEos X5 Controls and displays Controls on the inEos X5 inEos X5 features the following controls: Start key CAUTION Stopping motor movements By pressing and holding the Start key (A), all movements of the motor are immediately stopped and the motors are switched to a voltage- free state. -
Page 32: Operating State Led
7 Controls and displays Dentsply Sirona 7.2 Operating state LED Operating Instructions inEos X5 Operating state LED The LED shows the operating status of the unit: NOTICE Once the unit is switched on, the LED must light up in one of the following colors. -
Page 33: Switching The System On
Starting the software ➢ Start the software at the PC via the Windows start menu. Ä The inEos X5 automatically starts (if the main switch is turned on) as soon as you switch to the SCAN phase of the inLab CAD SW software. -
Page 34: Performing 3D Acquisition
9 Performing 3D acquisition Dentsply Sirona 9.1 General Operating Instructions inEos X5 Performing 3D acquisition General 9.1.1 Description of the SCAN phase 9.1.1.1 Complete overview of SCAN phase A Object list B Live image C Tools D Start scan E Help texts... -
Page 35: Object List
Dentsply Sirona 9 Performing 3D acquisition Operating Instructions inEos X5 9.1 General 9.1.1.2 Object list Description of the object list The object list with various functions is found on the left side of the display: ● The object list manages all objects (e.g. lower jaw, upper jaw, buccal). - Page 36 9 Performing 3D acquisition Dentsply Sirona 9.1 General Operating Instructions inEos X5 Status of objects Various characters/symbols that indicate the status of the respective object are visible on the object. Character/symbol Meaning (status) Mandatory element (disappears when object is scanned)
-
Page 37: Step Menu
Dentsply Sirona 9 Performing 3D acquisition Operating Instructions inEos X5 9.1 General Correlate function The Correlate button can be used to automatically correlate objects imported via STL with one another with a click. For example, the upper jaw or lower jaw can be automatically correlated with the respective upper jaw ( "Copy Upper"... -
Page 38: Acquisition Methods
9.1 General Operating Instructions inEos X5 9.1.2 Acquisition methods Four methods are available for acquiring scans with the inEos X5: ● Automatic jaw scan (e.g. complete capturing, reduced capturing) – For all tasks – Especially for large, complex tasks or tasks with high accuracy requirements ●... -
Page 39: Scan Modes
● When measuring scanbodies ● When capturing silicon impression trays with several multi-colored impression materials inEos X5 captures these situations using multiple exposure, so that every part of the surface is measured with the optimal exposure setting. Accordingly, the scan takes longer. -
Page 40: Scan Models And Impressions
9 Performing 3D acquisition Dentsply Sirona 9.1 General Operating Instructions inEos X5 9.1.4 Scan models and impressions Materials You can scan all materials that correspond to the following criteria: ● Non-reflecting ● Non-transparent ● No transparent parts ● Not highly absorbent (e.g. -
Page 41: Automatic Jaw Scan
Dentsply Sirona 9 Performing 3D acquisition Operating Instructions inEos X5 9.2 Automatic jaw scan Automatic jaw scan In "Capture Jaw" mode, you capture the model situation fully automatically. ● For all tasks. ● Especially for large, complex tasks or tasks with especially high accuracy requirements. -
Page 42: Taking The Scan
9.2.2 Taking the scan 1. Start the scan by pressing the Start button on the inEos X5 once. ➢ Alternatively, you can start the scan as follows: By pressing the "Enter" key on your keyboard once, by actuating the foot switch (optional) once or by clicking the "Scan"... -
Page 43: Guideline Editor
2. Start the automatic detail scan by double-clicking on the area of interest. Ä The inEos X5 positions the model in the scanning position with the rotation arm and automatically starts the scan. The image is automatically registered in the virtual model. -
Page 44: Free Scans
9 Performing 3D acquisition Dentsply Sirona 9.3 Free scans Operating Instructions inEos X5 Free scans In "Capture Free" mode, you quickly capture the model situation manually in a controlled manner. Moreover, you can scan e.g. areas that may not be sufficiently captured in the automatic mode with detail scans. -
Page 45: Automatic And Manual Release In The "Free Scan" Mode
Ä The crosshairs in the live image turn green. 2. Start the scans by clicking the "Scan" button in the software. ➢ Alternatively, you can press the Start button of the inEos X5 or press the Enter key on your keyboard. -
Page 46: Taking A Free Scan (Without Previous Automatic Scans)
9 Performing 3D acquisition Dentsply Sirona 9.3 Free scans Operating Instructions inEos X5 9.3.3 Taking a free scan (without previous automatic scans) 1. Align the model. Ä The model is aligned horizontally. Ä As many teeth as possible are visible in the live image. -
Page 47: Rotational Scans
Dentsply Sirona 9 Performing 3D acquisition Operating Instructions inEos X5 9.4 Rotational scans Rotational scans Select the single stump scan via the object list or step menu in order to scan single stumps from all sides. ● For the surveying of single tooth stumps ●... -
Page 48: Preparing The Optical Impression
For this, only position the same number of magnetic pots on the model plate as the number of stumps to be scanned. 2. Click the Start button of the inEos X5. ➢ Alternatively, you can start the scan process by clicking the "Scan"... -
Page 49: Acquiring An Occlusal Bite Registration
Dentsply Sirona 9 Performing 3D acquisition Operating Instructions inEos X5 9.5 Acquiring an occlusal bite registration Acquiring an occlusal bite registration You can secure the model using the articulator plate which is available as an option (see “Using the articulator plate [→ 62]”). -
Page 50: Example Applications
9 Performing 3D acquisition Dentsply Sirona 9.6 Example applications Operating Instructions inEos X5 Example applications 9.6.1 Scanning a crown preparation 1. Create a case ( "Crown" ) in the ADMINISTRATION phase. 2. Then continue to the SCAN phase. Ä The preparation to be scanned is pre-selected in the object list. - Page 51 Dentsply Sirona 9 Performing 3D acquisition Operating Instructions inEos X5 9.6 Example applications 6. If the alveolar ridge line was not correctly found automatically, you can correct this. Select the "Edit Jaw Line" tool and bring the alveolar ridge line to the correct position by moving the blue dots.
-
Page 52: Scanning An Impression
9 Performing 3D acquisition Dentsply Sirona 9.6 Example applications Operating Instructions inEos X5 11. Place the models with upper and lower jaw in the scanner and start the buccal scan by pressing the green "Start scan" button. 12. Click on the Next arrow. -
Page 53: Importing An Stl File
Dentsply Sirona 9 Performing 3D acquisition Operating Instructions inEos X5 9.6 Example applications 9.6.3 Importing an STL file 1. Create a case in the ADMINISTRATION phase. 2. Then continue to the SCAN phase. Ä The jaw of the preparation to be scanned is pre-selected in the object list. -
Page 54: Scanning An Occlusal Rim
9 Performing 3D acquisition Dentsply Sirona 9.6 Example applications Operating Instructions inEos X5 Ä The scanbody is recorded via a rotation scan and illustrated in the 3D preview once the scan is complete. 6. Continue with other implant positions. 7. After recording the scanbodies, continue scanning the other necessary models. - Page 55 Dentsply Sirona 9 Performing 3D acquisition Operating Instructions inEos X5 9.6 Example applications 3. Place the lower jaw on the arm of the scanner as specified by the reference picture and text. 4. Start the scan using the green "Start scan" button.
-
Page 56: Importing An Occlusal Rim
9 Performing 3D acquisition Dentsply Sirona 9.6 Example applications Operating Instructions inEos X5 Ä The scans are now correlated. 12. Click on the Next arrow. Ä The SCAN phase is finished and the model is loaded. 9.6.5.1 Importing an occlusal rim When you import the occlusal rim as an STL file, an automatic correlation is not performed. -
Page 57: Scanning A Triple Tray
Dentsply Sirona 9 Performing 3D acquisition Operating Instructions inEos X5 9.6 Example applications 9.6.6 Scanning a triple tray 1. Click the "Add Object" button. 2. Click the "Triple Tray" object. 3. Position the impression tray as per the illustrations in the software. -
Page 58: Regular Function Test Of The Light Barrier And The Start Key
10 Regular function test of the light barrier and the Start key Dentsply Sirona Operating Instructions inEos X5 Regular function test of the light barrier and the Start key The light barrier and Start key function test must be performed by a fully qualified specialist (experienced user, owner or service technician) every 12 months and the results must be documented. - Page 59 The operating state LED stays Error state green or switches to yellow. Call customer service. No maintenance other than the light barrier and Start key function tests described above must be performed on the inEos X5 . 64 17 096 D3586 D3586.201.01.16.02 2023-12...
-
Page 60: Cleaning And Care
7. If further cleaning is required, clean the optical surfaces using a dust and lint-free soft cotton swab and a little ethanol (standard alcohol for cleaning) or acetone. 8. Switch on the inEos X5 at the main switch and restart the software. 64 17 096 D3586 D3586.201.01.16.02 2023-12... -
Page 61: Accessories
X5 during free or automatic scans. Please use Blue filling material when attaching the model. ● Parallel vise magnetic coupling for attaching models or impressions to the ball joint model holder or the articulated arm of the inEos X5 during free or automatic scans. ● Prosthesis holder (1x). -
Page 62: Using The Articulator Plate
2. Place the articulator plate in the working area of the inEos X5 in such a way that the buccal scan can be taken. 12.2... -
Page 63: Using The Prosthesis Holder
1. Attach the bite rim to the prosthesis holder. For example, use blue- tack filling material. 2. Position the prosthesis holder with bite rim in the inEos X5 as shown in the pictures here. 64 17 096 D3586... -
Page 64: Disposal
13 Disposal Dentsply Sirona Operating Instructions inEos X5 Disposal In accordance with Directive 2012/19/EU and national disposal regulations regarding old electrical and electronic devices, please be advised that such items must be disposed of in a special way within the European Union (EU). - Page 65 Dentsply Sirona 13 Disposal Operating Instructions inEos X5 IMPORTANT Operators of equipment with storage functions for customer and patient data are responsible for deleting all personal data before disposing of the equipment. 64 17 096 D3586 D3586.201.01.16.02 2023-12...
- Page 66 We reserve the right to make any alterations which may be required due to technical improvements. © SIRONA Dental Systems GmbH Sprache: englisch Printed in Germany D3586.201.01.16.02 2023-12 Ä.-Nr.: 134 566 SIRONA Dental Systems GmbH 64 17 096 D3586 Fabrikstraße 31 Order No ...
