X-Smart® Apex Locator
Settings
menu
Sound level
adjustment
Getting Started
Disconnect the charger from the device if connected. Before connecting the measurement cable
with attached lip clip and file clip to the patient, plug the measurement cable into the device.
Turn on the device
by pressing On/Off
button.
Battery status indication
When the battery is low
(lower than 25%), battery
indicator will turn blinking
red, means that the battery
requires recharging.
Attach the lip clip
to the patient.
Charging
During battery charging,
charging screen is activated
with battery symbol and
battery level (percentage)
on the screen.
Duration of charging:
Approximately 3 hours.
Battery level
On/Off button
Gently insert the
file into the canal.
Receptacle for measurement
cable or charger cable
Connect the file clip
or touch probe to
the metal shaft of
the file.
Battery replacement
X-Smart® Apex Locator is powered
by a lithium-ion rechargeable
battery.
Contact your Dentsply Sirona
representative for battery
replacement.
Lip Clip
File Clip
Two initial beeps
indicate closed
measurement circuit
and beginning of
length determination.
Advertisement
Related Manuals for Dentsply Sirona X-Smart Apex Locator
Summary of Contents for Dentsply Sirona X-Smart Apex Locator
- Page 1 (percentage) Contact your Dentsply Sirona requires recharging. on the screen. representative for battery replacement. Duration of charging: Approximately 3 hours.
- Page 2 Tips for Successful Length Determination Coronal / medial section Sound is activated very apical close to region Apical region Mid-Apical region Minor Apical Foramen Over - instrumentation Absence of the two beeps audio signal indicates a faulty connection. Disconnect the measurement cable from the patient and check cable connections (see IFU, 6.5), clean the file clip and the lip clip, moisten the canal if necessary and start again.
