Installing/mounting
5.2 Installation instructions
5. Tighten the clamp ring on
6. Place the coarse aligning
7. There should be a light
8. By sliding the coarse align‐
42
the aiming piece rim.
unit inside the aiming
piece base.
spot visible on the coarse
aligning unit screen. If the
spot is not visible, check
whether the light source is
switched on.
ing unit, the bright spot
may be focused on the
screen. Find a position at
which the spot becomes
the smallest and sharpest.
Clamp ring tightening
Coarse aligning unit
Light spot visibility
Finding the spot
Operating Instructions, 05/2023, A5E51429088_AA
SITRANS TDL
