Siemens SITRANS SL Operating Instructions Manual

Continuous gas analysis, in situ laser gas analyzers
Hide thumbs Also See for SITRANS SL:
Table of Contents

Advertisement

Quick Links

Download this manual
Continuous gas analysis
In situ Laser Gas Analyzers
SITRANS SL
Operating Instructions
12/2010
A5E01132948-04
Introduction
Description
Application planning
Installing
Explosion protection
Commissioning
Operation
Interfaces to automation
systems
Service and maintenance
Alarm, error, and system
messages
Technical data
Dimension drawings
Spare parts and accessories
Appendix
List of abbreviations
1
2
3
4
5
6
7
8
9
10
11
12
13
A
B

Advertisement

Table of Contents
loading

Related Manuals for Siemens SITRANS SL

Summary of Contents for Siemens SITRANS SL

  • Page 1 Introduction Description Application planning Continuous gas analysis Installing In situ Laser Gas Analyzers SITRANS SL Explosion protection Commissioning Operating Instructions Operation Interfaces to automation systems Service and maintenance Alarm, error, and system messages Technical data Dimension drawings Spare parts and accessories...

  • Page 2: A5E01132948

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Product characteristics.........................30 Application planning..........................31 Cable selection recommendations....................31 Network and system integration....................32 3.2.1 Overview ............................32 3.2.2 Analog I/O and digital I/O system configuration................33 3.2.3 PROFIBUS DP system configuration ..................35 3.2.4 Modbus system configuration ......................37 SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 4 FM ............................... 78 5.2.1 Introduction ..........................78 5.2.2 Safety information ........................78 5.2.3 Installation of the FM version of SITRANS SL ................81 5.2.4 FM system set-up........................82 5.2.5 Electric connections in the FM system..................84 SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 5 Cyclic data transmission over PROFIBUS.................132 8.1.4.1 Cyclic data structure ........................132 8.1.4.2 Quality byte ..........................133 Modbus interface ........................136 8.2.1 Modbus installation ........................136 8.2.2 SITRANS SL Modbus map for gas measurement ..............137 8.2.3 Quality byte coding ........................138 8.2.4 Modbus adresses........................141 8.2.4.1 Standard Modbus........................141 8.2.4.2 Enron Modbus..........................143 8.2.4.3...
  • Page 6 ESD (ElectroStatic Discharge) ....................196 Verification Sheets ........................198 Service and support ........................201 Returned deliveries ........................202 A.5.1 Returned deliveries form ......................203 A.5.2 Decontamination declaration..................... 204 List of abbreviations..........................205 Glossary ..............................209 SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 7: Introduction

    – NEW: "Service and support" – NEW: "Interfaces to automation systems" – NEW: "Glossary" Revision of contents and layout 07/2010 Carbon monoxide (CO) introduced as measuring gas  Update of contents and layout 12/2010 SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 8: Product Versions

    Introduction 1.3 Product versions Product versions The product version number is found under the article number on the nameplate (see following figure). SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 9: General Information

    Siemens regional office. Note In particular, before using the device for new research and development applications, we recommend that you first contact your Siemens representative or our application department to discuss the application in question. Special information and warnings This manual provides you with information on using, installing, operating, and maintaining the device.

  • Page 10: Warranty Conditions

    All obligations on the part of Siemens AG are contained in the respective sales contract, which also contains the complete and solely applicable liability provisions. The provisions defined in the sales contract for the responsibility for defects are neither extended nor limited by the remarks in this document.

  • Page 11: Description

    Description Overview SITRANS SL is a diode laser gas analyzer with a measuring principle based on the specific light absorption of different gas components. SITRANS SL is suitable for fast, non-contact measurement of gas concentrations in process or flue gases. An analyzer consisting of transmitter and receiver unit (sensors) is used for each measuring point.

  • Page 12: Benefit

    2.2 Benefit Benefit The in-situ SITRANS SL gas analyzer features high operational availability, unique analytical selectivity, and a wide range of possible applications. SITRANS SL permits measurement of a gas component directly in the process: ● With high dust load ●...

  • Page 13: Range Of Application

    ● Process measurements in all types of power and combustion plants ● Process control ● Explosion protection ● Measurements in corrosive and toxic gases ● Quality control An overview of standard applications can be obtained from Technical data (Page 181), section 'Standard applications'. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 14: Design

    2.4 Design Design The SITRANS SL gas analyzer consists of a pair of cross-duct sensors - a transmitter unit and a receiver unit - both with the same dimensions. The complete analyzer is integrated in these two enclosures (pos. 1 and 7, fig. 2.2). The transmitter unit contains the laser source which light is transmitted to the receiver through the measurement path.
  • Page 15 The sensor connection cable is used to connect the transmitter unit to the receiver unit. This can be done either directly, or via a receiver junction box (see preceding figure). A sensor connection cable kit is available as accessory. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 16 ⑳ Connection cable ⑩ ATEX cable gland Figure 2-3 Design of the ATEX version of the SITRANS SL system See also Electric connections in the ATEX system (Page 73) Electric connections in the FM system (Page 84) SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 17: Display And Control Panel

    ● Remote operation via infrared interface for safe use in hazardous zones. ● Remote control using membrane keypad and softkeys which are easy to clean. Figure 2-4 Local user interface (LUI) of SITRANS SL in the receiver unit (display of measured value) Figure 2-5...

  • Page 18: Cables For Connection

    Electric connections in the ATEX system (Page 73). ● The ATEX version of the SITRANS SL is delivered with a sensor connection cable of the ordered length. This sensor connection cable must be connected between the Ex-e junction boxes mounted on the receiver and the transmitter.

  • Page 19: Inputs/Outputs

    ● 1 Ethernet 10Base-T port, only for service and maintenance. Using Ethernet, the analyzer supports the following software: – LDSComm (PC software for service and maintenance engineers) – SITRANS SL updater (PC software for service engineers) Note For the non-Ex version the junction box of the sensor connection cable kit is required for permanent installation of an Ethernet cable.

  • Page 20: Functional Description

    Typical spectral bandwidth of an absorption line compared to the bandwidth of the laser light. The field design of the SITRANS SL in-situ gas analyzer consists of a transmitter unit and a receiver unit. The light which is not absorbed by the sample is detected in the receiver. The concentration of the gas component is determined from the absorption.
  • Page 21 SITRANS SL and therefore must be considered for each new application. The standard applications listed in the ordering data for the SITRANS SL are distinguished in that the typical process conditions are adequately well-known and documented. If you cannot find your application among the standard applications, please contact Siemens AG.

  • Page 22: Influences On The Measurement

    The optical damping increases exponentially at longer path lengths. Smaller particles also have a very large influence on the optical damping. With high dust load, long path length and small particle size, the technical support at Siemens AG should be consulted.
  • Page 23 Adjustment of the sensor pair The process flanges of the SITRANS SL must be correctly aligned so that the laser beam generated by the transmitter hits the photodetector in the receiver unit. This is guaranteed in that the transmitter and receiver units have a curved surface integrated in the flanges. The adjustment is carried out by shifting the flanges on these surfaces, through which the symmetry axis is aligned.
  • Page 24 Inlet for purging on the process side Inlet for purging on sensor side if applicable ④ ⑧ Outlet for purging on sensor side Process interface if applicable Figure 2-9 Arrangement for purging on the sensor side of the SITRANS SL SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 25 Purging of sensors is always required for applications with oxygen as gas to be measured. The sensors are then continuously purged with nitrogen. The flow of purging gas required in this case is stated in the Technical data (Page 181). SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 26: Maintenance And Fault Messages

    2.5.3 Maintenance and fault messages The SITRANS SL carries out continuous self-monitoring, and outputs alarms and warnings to indicate maintenance requirements or a system fault. The information is output as plain text on the LUI display, where symbols identify the category and the severity of the fault.

  • Page 27: Essential Characteristics

    ● I/O operation in accordance with NAMUR recommendations. ● Monitoring of overall optical transmission. ● Sensor enclosure resistant to wear and corrosion. ● Local operation using remote-control unit with numeric keypad and menu prompting. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 28: Product Characteristics

    2.6 Product characteristics Product characteristics Device-specific characteristics SITRANS SL is designed for measurement of various gases. Details can be obtained from chapter Technical Data, standard applications section Transmission The system will have full performance when the transmission is within the range of 1 to 100 %.

  • Page 29: Application Planning

    Cable selection recommendations Note  For a normal (non Ex) setup of SITRANS SL the cables are not part of the standard delivery and should be ordered as an accessory.  An Ethernet cable may be permanently connected via the receiver junction box. Ethernet is needed for service and maintenance work.

  • Page 30: Network And System Integration

    Note Setup of the SITRANS SL can be done via the local user interface LUI, or for service engineers, via the LDSComm software. LDSComm communicates with SITRANS SL via Ethernet using the TCP/IP protocol. The connection can be established locally or via modem dial-in using the remote service kit which is available as accessory.

  • Page 31: Analog I/O And Digital I/O System Configuration

    Example of a system configuration with analog I/O and digital I/O System features: ● The SITRANS SL is controlled by the automation system via analog I/O and digital I/O. ● The measurement results of the SITRANS SL are output to the automation system via analog output.
  • Page 32 SITRANS SL Analyzer PLC (e.g. S7-315-2DP) Automation system Analog configuration From automation system to analyzer Siemens SIMATIC MPI Cable For PLC configuration I/O-module (e.g. SM374) – in/out16 (optional) For connecting external sensors External sensors (optional) For process gas temperature and pressure...

  • Page 33: Profibus Dp System Configuration

    System features: ● The SITRANS SL is controlled by the automation system via PROFIBUS DP. ● The measurement results from the SITRANS SL are output to the automation system via PROFIBUS DP. ● When external sensors are to be connected the first choice to do so is to use PROFIBUS DP although connection via analog input of the automation system is also possible.
  • Page 34 Comment SITRANS SL PROFIBUS Slave PLC (e.g. S7-315-2DP) PROFIBUS Master PROFIBUS Cable For PROFIBUS Master – Slave configuration Siemens SIMATIC MPI Cable For PLC configuration External sensors (optional) For process gas temperature and pressure Software Name Comment PROFIBUS system software (e.g. SIMATIC...

  • Page 35: Modbus System Configuration

    System features: ● The SITRANS SL is controlled by the automation system via Modbus. ● The measurement results of the SITRANS SL are output to the automation system via Modbus. ● When external sensors are to be connected the first choice is to use Modbus although connection via the analog input of SITRANS SL is also possible.
  • Page 36 Modbus Slave PLC (e.g. S7-315-2DP) Automation system Modbus module CP442-5 Modbus Master Modbus Cable For Modbus Master – Slave configuration Siemens SIMATIC MPI Cable For PLC configuration External sensors (optional) For process gas temperature and pressure Software Name Comment Modbus system software (e.g. SIMATIC Manager...

  • Page 37: Installing

    American market (FM approved version available). Laser safety SITRANS SL is classified as a class 1 laser product. The emitted laser light is invisible (near infrared) and not hazardous to the unprotected eye. SITRANS SL has warning labels at appropriate positions according to EN 60825-1:2007.

  • Page 38: Mounting

    The front (lid) side of the units must be accessible. To facilitate maintenance and service there shall be at least 60 cm of free space in front of SITRANS SL transmitter and receiver respectively. To meet the safety requirements for air convection and cooling there must be a free space of at least 10 cm around the SITRANS SL.

  • Page 39: Preparations

    If longer flange tubes are needed for any reason customized purging tubes (longer) have to be used. If you require further information, you can request the required information from your Siemens contact person. You will find details of your local contact persons over the Internet. For details see Service and support (Page 201) ①...
  • Page 40 Installing 4.2 Mounting At installation of the SITRANS SL, the laser and the photo-detector have to be aligned to the optical axis of the sensor pair. Note that each sensor has an optical axis of its own which is its axis of symmetry. In addition the sensor body is at an angle to this axis. The reason for this is that the laser beam passes a wedged window before exiting.

  • Page 41: Installation Of Process Flanges

    Figure 4-3 Flange alignment To be able to set the correct path length in SITRANS SL the dimension A in the 'Flange alignment' figure has to be measured after the flanges are mounted. The total length of the purging tube (dimension B), including the process flange must also be known.

  • Page 42: Installation Of The Sensors

    2. Mount the receiver and transmitter, both with gaskets on the flanges and cross-tighten the bolts. 3. Align the sensors as described in section Alignment of SITRANS SL (Page 57). CAUTION Do not install sensors that require purging before the purging media is accessible. Never leave a purged sensor with the purging media switched off since the process windows can be easily damaged.

  • Page 43: Installation Of The Purging Tubes

    The purging tubes are mounted by clamping the purging tube flange between the ② ④ customer flange and the SITRANS SL process interface . The sealing is accomplished ③ by the two process gaskets as shown in the following figure. ①...

  • Page 44: Electric Connections Non Ex

    The following must be observed when operating SITRANS SL: WARNING Never switch on or operate an analyzer with the lid open. The protective earth terminal of the SITRANS SL needs to be connected to the local potential equalization system. See also...

  • Page 45: System Set-Up (Non Ex Only)

    Receiver junction box Receiver housing ⑯ Receiver junction box cable ⑧ Connection cable (accessory) ⑰ Cable gland for Ethernet cable Figure 4-5 Connection of a non Ex system using a sensor connection cable kit SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 46: Screw Terminals

    CAUTION Damage to the equipment Damage to the equipment may result from short-circuit. No conductors of a cable may be left unconnected inside the SITRANS SL receiver or transmitter. Any unused conductor must be connected to the analyzer housing. NOTICE...
  • Page 47 PROFIBUS und Modbus ② ⑤ Diagram circuit terminals Terminals ③ ⑥ Buttons for LUI navigation Ethernet connection Figure 4-6 Control panel with switch for termination resistor in receiver housing Figure 4-7 Diagram circuit terminals SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 48 Installing 4.3 Electric connections non Ex Transmitter housing ① Terminals Figure 4-8 Transmitter board with terminals Figure 4-9 Transmitter circuit terminals SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 49 Installing 4.3 Electric connections non Ex Receiver junction box ① ② Receiver junction box cable Junction box Figure 4-10 Receiver junction box cable and junction box SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 50: Connecting Cables

    4.3.3 Connecting cables Sensor connection cable The sensor connection cable connects the receiver and the transmitter of the SITRANS SL. The sensor connection cable is used to transfer: ● 100 kbps RS-485 communication and synchronization ● power for the transmitter ●...
  • Page 51 Com + Grey Com - RS485 communication White Sync+ Brown Sync - Grey-Pink Tx + Red-Blue Tx - Ethernet connection Black Rx + Violet Rx - Green PE terminal Yellow PE terminal Shield Gland SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 52 Supported relay modes: "Normally Energized" (default), "Normally De-Energized". For configuration, see Configuration (Page 116). We recommend not to connect the connection cable directly to Ethernet connectors. Instead the sensor connection cable kit should be used for this purpose. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 53 Details to PROFIBUS connection and operation can be obtained from Section (Page 129) Example: Digital out 0 Figure 4-11 Using digital output ● V can be maximum 30 V DC. ● R must be minimum 60 Ω (max. 0.5 A in the relay). load SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 54 ((V – 7.5 V)/0.025 A) Ω. load Note SITRANS SL provides no supply voltage for the analog outputs, i.e. the analog outputs of the SITRANS SL are passive and thus must be powered externally! SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 55: Alignment Of Sitrans Sl

    4.4 Alignment of SITRANS SL Alignment of SITRANS SL Both sensors of the SITRANS SL have to be aligned such that the laser beam from the transmitter hits the photo detector in the receiver. To facilitate this both transmitter and receiver have a spherical surface incorporated in the flanges.

  • Page 56: Alignment Kit

    The alignment kit is not part of the delivery. If you commission the analyzer yourself, you need to order the alignment kit additionally. The alignment kit is necessary to align SITRANS SL. It consists of: ● a light source ● an alignment tool consisting of –...

  • Page 57: Alignment Procedure

    Installing 4.4 Alignment of SITRANS SL 4.4.2 Alignment procedure CAUTION Alignment procedure Correct alignment is crucial for proper operation of the analyzer. The alignment procedure has to be carried out with utmost care. 1. Before mounting the alignment kit, make sure that the contact surface between flange and the alignment kit is clean.
  • Page 58 Installing 4.4 Alignment of SITRANS SL The complete procedure for the alignment is described as follows starting with the receiver side. Note It is also possible to start with the transmitter side but it is always necessary to align both sides.
  • Page 59 Installing 4.4 Alignment of SITRANS SL Now go to the transmitter side! Release the clamp ring on the TTU (transmitter tube unit) using the wrenches. Support the transmitter when releasing. Remove the TTU. Remove the fine aligning unit from the aiming tool base by loosening the securing screw without taking it off.
  • Page 60 Installing 4.4 Alignment of SITRANS SL Now you will see a light spot from the light source, provided it is turned on. Focus by moving the outer part as indicated in the adjacent figure until you get the smallest and sharpest possible spot.
  • Page 61 Installing 4.4 Alignment of SITRANS SL 11. Now you will see a bigger light spot from the light source. Focus by moving the outer part as indicated in the adjacent figure until you get the sharpest possible spot. Align the transmitter using...

  • Page 62: Purging

    When measuring CO also purging of the sensor may be considered. Normally the CO content in standard air is lower than the detection limit of SITRANS SL. Nevertheless, the CO content may be higher inside buildings and industrial plants due to exhalation or combustion processes.

  • Page 63: Process Side Purging

    Always install the purging system before you install the sensors to avoid damage to the optics during the rest of the installation process. For optimal results use sensors equipped for the specific purging type, supplied by Siemens AG. SITRANS SL...

  • Page 64: Purging Set-Up

    Sensor purging output PI (Process interface) Figure 4-15 Sensor purging input with needle valve Note When using a plastic tube for connecting the purge gas supply, be sure to use the supplied rigid metal insert. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 65: Explosion Protection

    5.1.1 Safety information Electric Safety The SITRANS SL ATEX version is delivered with an approval for use in hazardous environments in which explosive gases are in use. WARNING Observe the specifications of the examination certificate valid in your country. Observe the laws and regulations valid in your country for the electric installation in hazardous areas with risk of explosion.
  • Page 66 WARNING Before switching on the analyzer make sure that the housing is closed and grounded. The protective earth terminal of the SITRANS SL needs to be connected to the local potential equalization system. Death, personal injury and/or damage to property may result if this is not observed.
  • Page 67 An absolute condition for the approval is that the equipment is setup according to ATEX system set-up (Page 71) . Liability Following commissioning, the total responsibility is with the owner. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 68: Installation Atex

    The installation of the ATEX sensors can be performed by the customer provided the instructions given in the certificate are fully observed. CAUTION The ATEX certificate is a system certificate and is only valid if SITRANS SL is installed according to the instructions given in the certificate. Note SITRANS SL must be shut off and disconnected before reconnections are done.

  • Page 69: Atex System Set-Up

    Figure 5-2 Overview of the ATEX version of SITRANS SL SITRANS SL is delivered with the cables already connected in the receiver and the transmitter. The cable to the customer side is approximately 3 meters long and must be connected in a junction box (not part of the delivery) in which the customer cable is joined to ⑮...
  • Page 70 ⑨ Country of origin Article number ⑤ ⑩ Measuring range Product name Figure 5-3 Example: ATEX label SITRANS SL Figure 5-4 Warning label SITRANS SL 1/2" NPT Figure 5-5 Thread size label SITRANS SL SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 71: Electric Connections In The Atex System

    The tables below illustrate the connections in the main junction box providing all in- and output connectors to the SITRANS SL. The terminals as well as their assignment are described in chapter Screw terminals (Page 48) . Sensor connection cable The sensor connection cable connects the junction boxes at the receiver and transmitter of the SITRANS SL.
  • Page 72 Remarks Function board) 24 V DC power supply to transmitter unit Blue Pink Com+ Grey Com- RS 485 communication White Sync+ Brown Sync- Green Chassis PE terminal Yellow Chassis PE terminal Shield Gland Gland SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 73 Maximum possible power consumption. Maximum input values. Maximum output values. The following figures show how the outputs are used. Supported relay modes: "Normally Energized" (default), "Normally De-Energized". For configuration, see section Configuration (Page 116). SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 74 Shield wire PROFIBUS shield Example: Digital out 0 Figure 5-6 Using digital output ● V can be maximum 30 V DC. ● R must be minimum 60 Ω (max. 0.5 A in the relay). load SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 75 7.5 V DC and maximum 30 V DC. ● R can be maximum ((V – 7.5 V)/0.025 A) Ω. load Note The analog outputs of the SITRANS SL are passive and thus must be powered externally! SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 76: Introduction

    WARNING The FM certificate is a system certificate and is only valid if SITRANS SL is installed according to the instructions given in the certificate. 5.2.2...
  • Page 77 WARNING Before switching on the analyzer make sure that the housing is closed and grounded. The protective earth terminal of the SITRANS SL needs to be connected to the local potential equalization system. Death, personal injury and/or damage to property may result if this is not observed.
  • Page 78 An absolute condition for the approval is that the equipment is set up according to FM system set-up (Page 82). Liability Following commissioning, the total responsibility is with the owner. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 79: Installation Of The Fm Version Of Sitrans Sl

    The installation of the FM sensors can be performed by the customer provided the instructions given in the certificate are fully observed. CAUTION The FM certificate is a system certificate and is only valid if SITRANS SL is installed according to the instructions given in the certificate. Note SITRANS SL must be shut off and disconnected before reconnections are done.

  • Page 80: Fm System Set-Up

    1.5 meter (5 ft) since it will be used as sensor connection cable when the calibration of SITRANS SL is verified. In this process the end in the junction box will be mounted in the transmitter and the cable length must be sufficient to mount the sensors and the calibration verification module as described in the FM verification section.
  • Page 81 Datamatrix code Product version ④ ⑨ Country of origin Article number ⑤ ⑩ Measuring range Product name Figure 5-10 Example: FM label SITRANS SL Figure 5-11 Warning label Figure 5-12 Note label SITRANS SL SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 82: Electric Connections In The Fm System

    The terminals as well as their assignments are described in section Screw terminals (Page 48). Sensor connection The sensor connection connects receiver and the transmitter of the SITRANS SL. The sensor connection is used to transfer: ● 100 kbps RS-485 communication ●...
  • Page 83 Certified PROFIBUS wiring recommended, see section PROFIBUS DP interface (Page 129) We recommend not to connect the connection cable directly to Ethernet connectors. Instead the sensor connection cable kit should be used for this purpose. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 84 ((V – 7.5 V)/0.025 A) Ω. load Note SITRANS SL provides no supply voltage for the analyzer outputs, i.e. the analog outputs of the SITRANS SL are passive and thus must be powered externally! See also Screw terminals (Page 48)

  • Page 85: Commissioning

    The user must also be familiar with the connection and operation of: ● Analog and digital pressure and temperature sensors, e.g SITRANS P or SITRANS T ● PROFIBUS DP and SIMATIC Manager when using the PROFIBUS-enabled SITRANS SL analyzer; ● Modbus protocol and Modbus system configuration when using the Modbus-enabled...

  • Page 86: Starting Sitrans Sl For The First Time

    This zone will depend on the purging flow and the flow of the measurement gas. The path length is entered into SITRANS SL, preferably using the remote control. The path length is the distance (l) according to the following figure. For measuring the path length (l) refer also to Installation of process flanges (Page 43).

  • Page 87: Further Input Parameters

    This enables an optimal quantity of the data to be transmitted. In the Siemens control system, the GSD files of all commonly used devices are already available. These GSD files are also available on the Internet for a subsequent import.

  • Page 88: System Integration

    The user data which are provided over the PROFIBUS line to the process control system are based on the target configuration. The following example is from a Siemens STEP7 project, and demonstrates how to configure the cyclic DPV0 data exchange.

  • Page 89: Pg/Pc Interface Setting

    The SIMATIC MPI cable setting has to be made using the "Set PG/PC Interface" window from the Options menu. Prerequisite: The connection between the PC and SITRANS SL has been established. The SIMATIC Manager is installed on the PC and the Windows XP operating system has been started. Procedure: Start the operating program "Set PG/PC Interface"...

  • Page 90: Loading Gsd File

    6.3 PROFIBUS configuration for SITRANS SL 6.3.5 Loading GSD file You use the SIMATIC Manager to load the GSD file of SITRANS SL. Procedure: Start the operating program "SIMATIC Manager" (start bar Start ➜ Programs ➜ SIMATIC ➜ SIMATIC Manager).
  • Page 91 Commissioning 6.3 PROFIBUS configuration for SITRANS SL 4. Select the "Install GSD file..." in the menu "Options". 5. Close the opened project in HW Config. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 92 Commissioning 6.3 PROFIBUS configuration for SITRANS SL 6. Navigate to the corresponding GSD file using the button "Browse" on your hard drive. 7. Mark in the selection list the GSD file and press the button "Install". 8. Finish the installation of the GSD file by pressing the button "Close".

  • Page 93: Network Configuration With Simatic Manager

    Commissioning 6.3 PROFIBUS configuration for SITRANS SL 6.3.6 Network configuration with SIMATIC Manager The SIMATIC Manager Step7 is the network configuration tool that will be used to configure the PROFIBUS DP network. SIMATIC Manager uses GSD files in order to know the properties of the devices in the network configuration.

  • Page 94: Creation Of A New Project With Simatic Manager

    Commissioning 6.3 PROFIBUS configuration for SITRANS SL 6.3.7 Creation of a new project with SIMATIC Manager You create a new STEP 7 project using the SIMATIC Manager. Procedure: 1. Start the operating program "SIMATIC Manager" (Start bar Start ➜ Programs ➜...
  • Page 95 Commissioning 6.3 PROFIBUS configuration for SITRANS SL 3. Click the button "Next". Reaction: The STEP 7 Wizard: "New Project" opens a dialog box for selecting the CPU. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 96 Commissioning 6.3 PROFIBUS configuration for SITRANS SL 4. Pick your required CPU from the selection list and click the button "Next". Reaction: The STEP 7 Wizard: "New Project" opens a dialog box for selecting the blocks. 5. In the selection list mark the check boxes for OB1 (program cycle execution block), OB100 (complete restart) and OB35.
  • Page 97 Commissioning 6.3 PROFIBUS configuration for SITRANS SL 6. Click the button "Next". Reaction: The STEP 7 Wizard: "New Project" opens a dialog box for setting the project name. Type the name or pick an existing one. 7. Click the button "Finish". Reaction: The STEP 7 project is created with the organization blocks OB1, OB100 and OB35.
  • Page 98 Commissioning 6.3 PROFIBUS configuration for SITRANS SL ● Optionally you can add the organization blocks from OB80 to OB88 with the menu command Insert ➜ S7 Block ➜ Organization Block. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 99: Hardware Configuration

    Commissioning 6.3 PROFIBUS configuration for SITRANS SL 6.3.8 Hardware configuration Creating PROFIBUS Network Procedure: 1. Double click on "Hardware" for opening "HW Config" in the selection list on the left hand side of the project window SIMATIC 300 Station. 2. In the selection list mark "(0)UR" DP item.
  • Page 100 Commissioning 6.3 PROFIBUS configuration for SITRANS SL PROFIBUS Network Configuration 1. Mark in the selection list "PROFIBUS(1): DP master system (1)" with the right mouse button. 2. Enter the dialog box 'Network Settings' in "Properties -PROFIBUS" 3. In the selection lists pick your object properties.
  • Page 101 6.3 PROFIBUS configuration for SITRANS SL SITRANS SL Configuration Prerequisite: ● SITRANS SL is selected from the hardware catalog and placed into PROFIBUS DP master system. ● The appropriate measurement type telegram is selected and placed into SITRANS SL slots starting from the first empty slot.
  • Page 102 Commissioning 6.3 PROFIBUS configuration for SITRANS SL 2. Select the subnet type from the selection list "Properties - PROFIBUS interface SITRANS SL". SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 103 Commissioning 6.3 PROFIBUS configuration for SITRANS SL 3. In the HW Config window you can check the number of blocks and the address assignment. Measurement Type Selection Concentration measurement output ● First input module in the first slot. Consists of 4 byte float value and 1 byte status value.

  • Page 104: Modbus Configuration For Sitrans Sl

    32 bit data type via a Modbus RTU message, the endianness of both master and slave must be ensured. SITRANS SL allows specific selection of byte orders, so you must take care that both units are set to the same byte order.

  • Page 105: Supported Modbus Functions

    Commissioning 6.4 Modbus configuration for SITRANS SL 6.4.3 Supported Modbus functions Modbus defines a set of data and control functions to perform data transfer and slave diagnostic. The following Modbus functions are implemented: ● 0x01 Read Coils ● 0x02 Read Discrete Inputs ●...
  • Page 106 Commissioning 6.4 Modbus configuration for SITRANS SL SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 107: Operation

    Local user interface (LUI) The local user interface consists of a digital display and four buttons. ① Digital display (measurement view) ② Buttons ③ Receiver for remote control signals Figure 7-1 Digital display and buttons SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 108 Operations via the buttons on the LUI PCB are only allowed for test and service purposes. Remote control SITRANS SL can be operated at site with an infrared remote control. This device is intrinsically safe and certified: according to ATEX...

  • Page 109: General

    ● The editing row, where the new value can be typed in ● Upper and lower limits for the parameter value NOTICE To enter the Edit display, the LUI must first be unlocked. Any entries of values outside the allowed range are discarded. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 110 + or - position) Cancel editing Move to the leftmost position, then press Confirm edited value Move to the rightmost position, then press Can not be done with the remote control. The input must be rewritten. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 111 The LUI will now inform that changes have been made and display the save settings dialogue. CAUTION After changing the settings exit the menu system and select OK when asked to save the settings. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 112: Measurement Views

    Gas component, e.g. O Pressure Temperature Transmission When not being edited, the SITRANS SL LUI displays the Measurement view containing the following information: ● Present measured components with corresponding Value and Unit. ● Alarm status icon or icons, if multiple alarms are trigged.

  • Page 113: Menu System

    Changes are saved when the main menu is exited. In the following menu structures white boxes indicate selection screens, grey boxes indicate edit screens, and black (inverted) boxes represent displays without any user interactions. Figure 7-3 The menu system SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 114: Configuration

    Operation 7.3 Menu system 7.3.2 Configuration Main Menu Configuration (edit) Figure 7-4 The setup menu SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 115 ● Absolute transmission ● Temperature ● Pressure An averaging filter is connected to each component. For each component the filter parameter "integration time" can be used to balance the needs of response time and noise reduction. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 116 "Normally Energized" refers to the state of the relay in normal operation. The relay contact for the alarm signal is closed in normal state of operation when checked. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 117 'Scaling' and 'Suppress negative values' can be edited. Before you can start editing the LUI must be unlocked. Analog output settings Set scale Suppress negative values LUI output settings Suppress negative values PROFIBUS output settings Suppress negative values Modbus output settings Suppress negative values SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 118: Diagnostics

    When the log book is opened the groups screen is first displayed, it gives an overview of the analyzers status. To get detailed technical information for a group, highlight the group and press Right key. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 119 381 days, 8 hours, 12 minutes and 34 seconds of runtime. Note that the time refers to systems total run time; the SITRANS SL does not have a real time clock. The groups are sorted by the time for the last event. The group which last had a change of status is on top of the list.

  • Page 120: Service

    Operation 7.3 Menu system 7.3.4 Service Figure 7-6 Service menu SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 121 Calibrate CAUTION Never use this function without having contacted Siemens service first! Inappropriate use of this function may seriously affect the accuracy of the analyzer. After selecting one of the gas components to be calibrated the calibration menu is displayed providing the following options: ●...
  • Page 122 The current reading for the selected input is displayed and continuously updated. Digital input test Sitrans SL provides one configurable binary input for quality information of external sensors. This binary input is mapped within the application software to input 0 and input 1. Both inputs are displayed and continuously updated.

  • Page 123: Communication

    Operation 7.3 Menu system 7.3.5 Communication Figure 7-7 The communication menu Note You can configure only Modbus or PROFIBUS parameters when SITRANS SL has been setup with the respective communication interface. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 124 Menu leads to the editing screen for the setting of ● PROFIBUS address After changing the parameter the analyzer must be reset before the new setting takes effect. Modbus see Modbus settings (Page 106) SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 125: Security

    ● Now select Diagnostics and open the log book. ● Select G6 ● The alarm E61 (LUI unlocked) is now active. ● The time stamp for this alarm is the system run time, Operating hours (DDDD HH:MM:SS). SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 126: Language

    Figure 7-9 The language menu Select language from the list of available languages. After change of language the analyzer must save settings (user confirmation) and then restart (user confirmation) before the new setting takes effect. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 127: Interfaces To Automation Systems

    ATEX variant is delivered with 3m of PROFIBUS hybrid cable mounted. Connecting to the bus To install the SITRANS SL as the single or as the last device of a PROFIBUS segment: 1. Ensure that the termination resistor is turned on.
  • Page 128 Interfaces to automation systems 8.1 PROFIBUS DP interface To install the SITRANS SL as a device in-between other devices on a PROFIBUS segment: 1. Ensure that the termination resistor is turned off. 2. Connect the PROFIBUS hybrid cable to the SITRANS SL receiver.

  • Page 129: Device Data Base Files (Gsd)

    For safe operation of PROFIBUS DP note the following points: ● Observe the general PROFIBUS guidelines for installation. ● When installing the SITRANS SL as the only analyzer, or as the last analyzer in a PROFIBUS DP network: – Ensure to switch on the terminal resistor on. The switch is found next to the screw terminals in the receiver unit.

  • Page 130: Cyclic Data Transmission Over Profibus

    Each value is represented as a 5 bytes value. The first four bytes build the measurement value, transmitted according to IEEE-754. The fifth byte is used for status. Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Value in IEEE-754 floating point Status Exponent Fraction SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 131: Quality Byte

    The quality byte has the following structure: Figure 8-1 Quality byte coding Note Error codes and alarm list For explanation and action of error codes and the alarm list refer to chapter Alarm, error, and system messages (Page 163) . SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 132 Status coding for "uncertain quality" Cause Remedy Maintenance demanded or process See alarm list. value warning or process value out of tolerance. Status coding for "good quality" Cause Remedy Normal operation. You can evaluate the measured values. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 133 Temperature: E13 Pressure: E17 Quality status of temp. or pressure is Temperature: E14 high limit. Pressure: E18 Quality status of temp. or pressure is Temperature: E15 constant. Pressure: E19 SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 134: Modbus Interface

    The SITRANS SL gas analyzer provides Modbus communication to a PC or an automation system via an RS485 interface. The SITRANS SL gas analyzer may be connected to a network. Such a network is normally built as a bus topology which needs to be terminated via RC termination plugs. The same applies to a point-to-point connection.

  • Page 135: Sitrans Sl Modbus Map For Gas Measurement

    8.2.2 SITRANS SL Modbus map for gas measurement Information from the SITRANS SL can be transferred to a PC/PG via the Modbus. Measurement values, status signals and also signals of analog and digital inputs and outputs are thus available for further usage.

  • Page 136: Quality Byte Coding

    Structure and meaning of quality byte: Figure 8-2 Quality byte coding Note Error codes and alarm list See for explanation and action of error codes and the alarm list chapter Alarm, error, and system messages (Page 163) . SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 137 Quality status of source is bad and temp. Temperature: E12 & E14 or pressure is high limit Pressure: E16 & E18 Quality status of source is bad and temp. Temperature: E12 & E15 or pressure is constant Pressure: E16 & E19 SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 138 Temperature: E13 Pressure: E17 Quality status of temp. or pressure is high Temperature: E14 limit Pressure: E18 Quality status of temp. or pressure is Temperature: E15 constant Pressure: E19 See also Quality byte (Page 133) SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 139: Modbus Adresses

    8.2.4.1 Standard Modbus ● The component value is transferred in IEEE 32 bit floating point format. SITRANS SL uses two word registers representing a floating point value. ● The measurement counter is transferred in 32 bit integer format. SITRANS SL uses two Word-Registers representing a 32 bit integer value.
  • Page 140 Component 3 – Pressure Value in mbar as IEEE 32 bit value 40004 Holding Register Component 4 – Temperature Quality 40005 Holding Register Component 4 – Temperature Value in °C as IEEE 32 bit value SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 141: Enron Modbus

    8.2 Modbus interface 8.2.4.2 Enron Modbus This section describes the Enron Modbus register group numbers for the SITRANS SL gas analyzer. Register numbers are used to identify specific data items to be read or written. Registers are grouped by data type.
  • Page 142 Component 4 – Temperature Time stamp – Minute 3021 read 3020 Component 4 – Temperature Time stamp – Second 3101 write 3100 Component 3 – Input Pressure Quality 3102 write 3101 Component 4 – Input Temperature Quality SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 143 7002 Component 3 – Pressure output value 7004 read 7003 Component 4 – Temperature output value 7101 write 7100 Component 1 – Pressure input value 7102 write 7101 Component 1 – Temperature input value SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 144: Modbus Alarm List

    Interfaces to automation systems 8.2 Modbus interface 8.2.4.3 Modbus alarm list The status information is transferred in 32 bit integer words. SITRANS SL uses four Word- Registers representing the detailed status information. Status Word 1 Status Register description DWORD BIT position...
  • Page 145 "Analog output test mode" "Digital output test mode" "EEPROM configuration missing" "Save settings failed" "Sensor temp. comp. file range" "Watchdog reset triggered" "LUI unlocked" "Hardware inconsistency" "A0 outside measurement range" "A1 outside measurement range" SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 146 Interfaces to automation systems 8.2 Modbus interface Status Word 3 Status Register description DWORD BIT position Description Error Code "Laser drift" "Algorithm error" "Measurement quality" "Line locking failure" Status Word 4 Not used. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 147: Service And Maintenance

    Service and maintenance Instrument verification The SITRANS SL should be verified within the time interval stated in the Technical data (Page 181). This procedure can be done by the customer or the Siemens Service. The verification of the instrument shall only be performed with the appropriate verification kit (see accessory list in section "Accessories (Page 193)").

  • Page 148: Verification With The Verification Tube

    Service and maintenance 9.1 Instrument verification 9.1.1 Verification with the verification tube The verification tube is intended for the oxygen version of the SITRANS SL (SITRANS SL Necessary equipment ● Verification kit ● Sensor connecting cable If your regular sensor connection cable cannot be removed from the installation, you need a supplementary one.

  • Page 149: Span Verification

    In order to document the verification procedure you should fill put the 'Verification sheet' form thoroughly during verification. 1. Make a copy of the "SITRANS SL O2 Verification sheet" form you can find in Appendix A. 2. Fill out the first part (General Information).
  • Page 150 90 % 18.4 100 % 18.2 Figure 9-2 Verification set point for different relative humidities and temperatures. Note If you do not use dry air, your oxygen concentration is lower due to the air moisture. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 151 1 052 hPa and a minimum of 950 hPa which corresponds to uncorrected oxygen readings between 21.78 % and 19.67 %. Although these are extreme values they point out the importance of having an accurate pressure value inside the tube. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 152 Note In the instruction it is assumed that totally oxygen free nitrogen is used. The concentration value of the SITRANS SL during this procedure will not be lower than the oxygen content in the nitrogen. 1. Attach your source of purging gas (N ) to the needle valve on either the receiever or transmitter side.
  • Page 153 If the average value lies outside this range, please contact Siemens support. 5. Put the removed needle valve back into place and close it. Repeat all steps of one of the paragraphs "Filling the verification tube with ambient air" or "Filling the verification tube with pressurized air"...
  • Page 154 After purging first close the lids. Then turn off the nitrogen and wait for 10 minutes. If the oxygen value remains below 0.15 vol %, the problem is solved. If not, repeat the procedure. See also Technical data (Page 181) Verification Sheets (Page 198) SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 155: Verification With A Verification Cell

    9.1 Instrument verification 9.1.2 Verification with a verification cell The verification cell is intended for the carbon monoxide version of the SITRANS SL (SITRANS SL CO). The verification module is mounted between the transmitter tube unit (transmitter) and receiver tube unit (receiver) during verification. The verification kit consists of a metal tube and a gas filled glass cell with a defined gas concentration stated in the corresponding certificate.
  • Page 156 9.1 Instrument verification Step 2: Preparations and LUI settings In order to document the verification procedure you should fill out the 'SITRANS SL CO Verification sheet' form thoroughly during verification. 1. Make a copy of the "Verification sheet" form you can find in Annex A.

  • Page 157: Verification Of Systems Used In Hazardous Areas

    If it lies within the range between the set point and the total verification uncertainty, the instrument works properly. If the average value lies outside this range, repeat the verification procedure. If the test still fails, contact Siemens support providing the filled-out verification sheet will all verification results. See also Verification Sheets (Page 198) 9.1.3...

  • Page 158: Cleaning The Optical Parts Of The Sensor

    Start the cleaning process at the center and work with circular movements towards the rim. 4. To remount the process interface, refer to section Installation . Also a new alignment of the sensors has to be carried out. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 159 If this operation is performed properly, it will not affect the alignment of the sensor. NOTICE Any work with the optical lens requires utmost care. The lens is anti-reflection coated and thus very susceptible to scratches! See also Mounting (Page 40) SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 160 Service and maintenance 9.2 Cleaning the optical parts of the sensor SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 161: Alarm, Error, And System Messages

    In this chapter the word 'alarm' is used as a general term without referring to the alarm level, i.e. if it is a failure, a warning or just informative. The actions to be taken when an alarm trigged are specific to each alarm. Figure 10-1 Alarm overview SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 162 Alarm, error, and system messages 10.1 Alarm Alarm Triggering Generally a SITRANS SL alarm has three parameters: ● Triggering level ● Triggering time (T ● Reset time (T Figure 10-2 Alarm triggering Alarms with different behaviours or configurations are handled later in this chapter under the alarm description.
  • Page 163 PROFIBUS and Modbus have two ways of reporting a problem, quality indication and alarm. Quality indication that comes with every cyclic data (measurements) and is either a value or one of the following states: ● Good ● Uncertain ● Bad SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 164 When being operated via PROFIBUS or Modbus, the PLC will notice that the SITRANS SL is missing on the bus if it does not start. In that case the PLC can generate an alarm.
  • Page 165 Example: The software is executing save settings. No data exchange Communication failure. Example: PROFIBUS master has been switched of. Write access on/off Write access on is used to indicate that the Local User Interface is unlocked. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 166 G10 Measurement out of range G11 Configuration error G12 Internal communication G13 PROFIBUS client The allocation of a specific alarm to its LUI alarm group is shown in table 10-1 "Alarm list (Page 170)". SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 167 Alarm, error, and system messages 10.1 Alarm Log book In the log book there are some more groups Figure 10-3 Log book groups SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 168: Alarm List

    5 minutes. Ensure that the ambient conditions are within the specifications for the SITRANS SL and restart the system if needed. The SITRANS SL has failed to lock on to the built in Line locking failure reference cell.
  • Page 169 Mismatch between receiver and transmitter versions e.g. Hardware Inconsistency when either the receiver or the transmitter has been replaced. Contact Siemens support. The laser is getting close to the limit of operation. Laser drift Contact Siemens support. SITRANS SL...
  • Page 170 Contact Siemens support. The process temperature deviates from the operational Compensation temp. file range range of this SITRANS SL application. The deviation is so large that no measurement value can be produced. Delimit process temperature or verify that the temperature sensor produces correct measurements.
  • Page 171 Check whether the measured gas concentration is reasonable. If so, contact Siemens support to evaluate if the measuring range can be increased. If the concentration seems incorrect it may be necessary to check path length, temperature correction and pressure correction.
  • Page 172 Symbol/Group Error Alarm (description) /Action Code EEPROM configuration missing. EEPROM configuration missing Contact Siemens support. Save settings failed. Save settings failed Contact Siemens support. Save settings active Configuration changed Analog output test mode The test mode for analog outputs is active...
  • Page 173 CO outside range Process value warning FPGA timeout receiver Maintenance fault FPGA timeout receiver junction Maintenance fault FPGA timeout transmitter Maintenance fault Laser unpowered Maintenance fault Transmitter board temperature Maintenance demanded Receiver board temperature Maintenance demanded SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 174 Maintenance demanded A0 outside measurement range Process value fault A1 outside measurement range Process value fault Laser drift Maintenance demanded CurveFit algorithm Maintenance fault Measurement quality Process value warning Line locking failure Maintenance fault SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 175: Profibus Diagnosis And Alarms

    Alarm, error, and system messages 10.3 PROFIBUS diagnosis and alarms 10.3 PROFIBUS diagnosis and alarms 10.3.1 Diagnosis and alarm handling in PROFIBUS DP Figure 10-4 Diagnosis and alarm handling in PROFIBUS DP SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 176: Meaning Of The Diagnosis Information

    "Laser current lower limit" Unit_Diag_Bit(46) "Ext. temperature uncertain" Unit_Diag_Bit(47) "Ext. pressure uncertain" Unit_Diag_Bit(48) "PROFIBUS configuration error" Unit_Diag_Bit(49) "PROFIBUS connection error" Unit_Diag_Bit(50) "PROFIBUS master switch off" Unit_Diag_Bit(51) "PROFIBUS internal error " Unit_Diag_Bit(52) "Temp. comp. file range" SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 177 "Sensor temp. comp. file range" Unit_Diag_Bit(83) "Watchdog reset triggered" Unit_Diag_Bit(84) "LUI unlocked" Unit_Diag_Bit(85) "Hardware inconsistency" Unit_Diag_Bit(86) "A0 outside measurement range" Unit_Diag_Bit(87) "A1 outside measurement range" Unit_Diag_Bit(88) "Laser drift" Unit_Diag_Bit(89) "Algorithm error" Unit_Diag_Bit(90) "Measurement quality" Unit_Diag_Bit(91) "Line locking failure" SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 178 Alarm, error, and system messages 10.3 PROFIBUS diagnosis and alarms SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 179: Technical Data

    CO: 0 ... 100 ppmv 1 m) Maximum measuring range O2: 0 ... 150 vol. % • m (measuring range * path length) CO: 0 ... 2 000 ppmv • m Calibration verification interval 1 year SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 180 Warm-up time at 20 °C/68 °F Start of measurement: < 5 min.  ambient temperature Full gas measurement accuracy: < 60 min.  Response time (T Approx. 2 s, depending on application Integration time 0 ... 100 s, selectable SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 181 1 input, designed for 24 V, floating, configurable Service port Ethernet 10BaseT (RJ-45) RS 485- PROFIBUS-DPV0 Two-wire interface, up to 3 Mbit/s, -7 ... + 12 V RS 485-Modbus Two-wire interface, up to 115 200 bit/s, -7 ... + 12 V SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 182 -20 ... +70 °C (-4 ... 158 °F) Temperature range at the sensor  side of the process interface (connection plate) Ambient pressure 800 ... 1 100 hPa (for ATEX and FM versions) Humidity < 100 % relative humidity (non condensing) SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 183 11.1 Technical data Measuring conditions Measuring conditions Measurement path 0.3 ... 8 m (other lengths: please contact Siemens AG) : 900 ... 1 100 hPa (absolute), 0 ... 600 °C Process gas pressure, temperature  (32 ... 1 111 °F) - applies to MLFB code AB : 700 ...
  • Page 184 The information provided in this chapter contains descriptions or characteristics of performance which in case of actual use may not apply as described as a result of further development of the product. Technical specifications are subject to change without further notice. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 185: Dimension Drawings

    Dimension drawings Dimension drawings 12.1 Dimensional drawings SITRANS SL can be delivered with two different process flanges - suitable for flange connections DIN (DN50/PN10-40) or ANSI (ANSI 4"/150lb). ① Purging tube ② Process interface ③ Process purging input ④ Receiver cable kit or transmitter cable junction box ⑤...
  • Page 186 Dimension drawings 12.1 Dimensional drawings Figure 12-2 Dimensional drawing customer flange DN50/PN10-40, all measures in mm (inches) Figure 12-3 Dimensional drawing customer flange ANSI 4"/150 lb, all measures in mm (inches) SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 187 375 (147 5/8”) Figure 12-4 Dimensional drawing calibration tube, all measures in mm (inches) ① Cable gland for sensor connection cable, M20 with plug Figure 12-5 Dimensional drawing transmitter junction box, all measures in mm (inches) SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 188 12.1 Dimensional drawings ① Cable gland for sensor connection cable, M20 with plug ② Cable gland for Ethernet cable, M16 with plug Figure 12-6 Dimensional drawing receiver junction box, all measures in mm (inches) SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 189: Spare Parts And Accessories

    A5E02522036 Gasket ANSI 4"/150 lbs. A5E02789535 Needle valve kit A5E02569944 Sensor connection cable 5 m A5E02571180 Sensor connection cable 10 m A5E02571184 Sensor connection cable 25 m A5E02571186 Cable gland kit non Ex A5E02568457 SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 190 A5E03000236 Spare parts for CO measurement Order No. Transmitter module CO A5E03000243 Receiver module CO A5E03000250 Transmitter module COATEX A5E03000246 Receiver module COATEX A5E03000251 Transmitter module CO FM A5E03000247 Receiver module CO FM A5E03000253 SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 191: Accessories

    WARNING The SITRANS SL sensor alignment kit is not Ex protected. Therefore it must never be used in a hazardous area without approval by the plant manager! Verification kit The SITRANS SL has already been factory-calibrated.
  • Page 192 A5E01000694 Verification kit CO A5E03090938002 The use of these accessories is described in one of the following sections: Alignment of SITRANS SL (Page 57) , Instrument verification (Page 149) , Connecting cables (Page 52) SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 193: Appendix

    Figure A-1 Purge air flow rate Note This figure represents a general context between pressure and flow rate. The maximum purge flow rate of the SITRANS SL on process side is limited to 50 Nl/min. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 194: Esd (Electrostatic Discharge)

    A latent defect, on the other hand, is more difficult to identify. It means that the device has only been partially degraded from exposure to an ESD event. Latent defects are extremely difficult to prove or detect using current technology, especially after the device is assembled into a finished product. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 195 "zero" voltage ground reference as long as all items in the system are at the same potential. It is important to note that non-conductors in an Electrostatic Protected Area (EPA) cannot lose their electrostatic charge by attachment to ground. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 196: Verification Sheets

    Verification Sheets Instrument Verification Albeit the SITRANS SL provides a high long-term stability due to the built-in, maintenance- free reference gas cell, a verification should be carried out at regular intervals. Details of that procedure are described in section 9.1. (Page 149) This procedure should be documented using the appropriate verification sheet provided later in this section.
  • Page 197 Appendix A.3 Verification Sheets SITRANS SL O Figure A-3 Verification Sheet SITRANS SL O2 SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 198 Appendix A.3 Verification Sheets SITRANS SL CO Figure A-4 Verification sheet CO SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 199: Service And Support

    The instructions are included on the CDs which are already supplied or may be ordered. In addition, the instructions are available on the Internet on the Siemens homepage. A signpost to the range of technical documentation, the online catalog, and the online ordering system for individual SIMATIC products and systems is available at our homepage (http://www.siemens.com/processanalytics)

  • Page 200: Returned Deliveries

    To enable fast detection and elimination of faults, please return the analyzers to the following address - until further notice: SIEMENS SPA Tel.: (00333)88906677 Fax: (00333)88906688 1, chemin de la Sandlach F-67506 Haguenau - DP order form receiver: 0011E SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 201: Returned Deliveries Form

    Serial no. Designation of returned part Fault description Process data at point of measurement Operating temperature Operating pressure Composition of sample gas Duration of use/ date of commissioning Process data at point of measurement SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 202: Decontamination Declaration

    Duration of use/ date of commissioning Confirmation It is herewith confirmed that all residues of the measured medium have been removed. The device is free of all dangerous and/or toxic materials. Location / date / signature SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 203: List Of Abbreviations

    Factory Mutual, certifying body in the USA for hazardous area approvals FPGA Field programmable gate array Foiled twisted pair Device master data file (German: Geräte-Stamm-Datei) Height unit for computer housings, 1 HU ≙ 1¾" ≙ 44.45 mm Kelvin Kilohertz SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 204 Quality Assurance Level Random Access Memory Receiver Housing Unit Receiver Tube Unit Receive (Rx) identifies a receiver Second SELV Safety Extra Low Voltage SM374 Simulation module 374 Sub-Miniature A, a coaxial connector type Screened twisted pair SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 205 Internet Transmitter Housing Unit Transmitter Tube Unit Transmit (Tx) identifies a transmitter Underwriters Laboratories, a US certifying body Volt Vol% Volume percent Volume parts per million Δ Difference (Greek: delta) μC Microcontroller SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 206 List of abbreviations SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

  • Page 207: Glossary

    Digital Representation of a variable, e.g. time, in the form of characters or numbers. In its digital representation, this variable can be changed only in pre-defined steps, in contrast to "Analog". SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 208 Date is sometimes saved in a different order in certain computer architectures. Intel-based computers, for example, save the data differently from the Siemens controllers (S7), namely, in reverse sequence. The byte sequence from Intel, termed Little Endian, is therefore the reverse S7 byte sequence, Big Endian.
  • Page 209 There are two versions of Modbus: one for the serial interface and one for Ethernet. MSB is the byte (or octet) in that position of a multi-byte number which has the greatest potential value. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 210 It is then possible to use significantly longer transmission links and higher speeds than with RS 232. Furthermore, several transmitters and several receivers can be connected to one pair of conductors. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 211 Zone 2 Area in which a dangerous, potentially explosive gaseous atmosphere usually doesn't form, or only for a short time period, during the normal operation of a device. SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...
  • Page 212 Glossary SITRANS SL Operating Instructions, 12/2010, A5E01132948-04...

Table of Contents
