ROBOTIQ POWERPICK20 Original Notice page 53

PowerPick20 Vacuum
Generation Unit
PowerPick20 Gripper Unit
75 mm suction cups
1 This SKU does not contain the PowerPick20 Gripper Unit or the PowerPick20 Vacuum Generation Unit.
2 This SKU does not contain the PowerPick20 Gripper Unit or the mounting bracket & filter-regulator assembly.
3 This SKU does not contain the PowerPick20 Vacuum Generation Unit.
- 4 x M8 x 20 mm socket head cap screws with
captive spring washer
PowerPick20 Controller Unit that includes
- 1 x PowerPick20 Vacuum Generator
- 1 x M12-12 pin I/O cable
PowerPick20 Gripper Unit 3
- 1 x Manifold assembly
- 1 x Small Suction cup bracket assembly
- 4 x Air nodes with 110 mm suction cups
- 1 x Large Suction cup bracket assembly
- 4 x 8 mm air tubes (275 mm)
- 1 x 12 mm double air tube (3.63 m)
- 1 x Tools and hardware for installation on UR20
Kit of 4 suction cups that includes:
- 4 x Piab 75 mm (1.5 bellows)
- 4 x 3/8 BSPP threaded adapters
Table 7-1: PowerPick20 Spare Parts, Kits and Accessories
2 :
:
PowerPick - Instruction Manual
VAC-POWERPICK20-CTRL-UNIT
VAC-POWERPICK20-GRP-UNIT
VAC-CUP-PIAB-75MM-G38-KIT-4
53
