1 x Large suction cup bracket assembly
l
1 x 12 mm double air tube (3.63 m)
l
4 x 8 mm air tubes (275 mm)
l
1 x Hardware kit:
l
1 x M8 shoulder screw
l
4 x M8 x 40 mm hex socket head cap screws with captive spring washer
l
10 x 190 mm cable ties
l
1 x Tubing curler
l
1 x Pneumatic adapter 1/2 BSPP to 12 mm tube
l
2 x M6 external tooth lock washers
l
1 x M6 flange nut
l
1 x Installation tool kit:
l
1 x 6 mm hex key, L-shape
l
1 x 21 mm / 24 mm double-ended wrench
l
1 x 200 mm hollow offset link kit (optional):
l
1 x 200 mm horizontal offset tube
l
4 x M8 x 20 mm hex socket head cap screws with captive spring washer
l
2 x 8 mm air tubes (275 mm)
l
2 x 8 mm air tubes (475 mm)
l
1 x 100 mm wrist extension kit (optional):
l
1 x 100 mm wrist extension
l
4 x M8 x 20 mm hex socket head cap screws with captive spring washer
l
1 x 75 mm suction cup kit (optional):
l
4 x 75 mm suction cups
l
4 x 3/8 BSPP threaded adapters
l
