ATTENTION:
• The length of the exposed wires in the stripping process is important.
The ideal length is 3/16 inch (5 mm). Any longer and the exposed wires may
touch, causing a short circuit between them. Any shorter and the wires can be
easily pulled out even if tightly fastened by the captive screws.
• La longueur des câbles exposés est importante lorsque l'on entreprend de les
dénuder La longueur idéale est de 5 mm (3/16 inches). S'ils sont trop longs,
les câbles exposés pourraient se toucher et provoquer un court-circuit. S'ils
sont trop courts, ils peuvent être tirés facilement, même s'ils sont correctement
serrés par les borniers à vis.
NOTE: Do not tin the power supply leads before installing them in the direct insertion
connector. Tinned wires are not as secure in the connectors and could be pulled
out.

Outputs

Line audio output
F
amplifier, unified communication platforms, recording or assistive listening device
to this 3.5 mm captive screw 5-pole connector. It can be wired as balanced or
unbalanced.
Tip
NO Ground Here
Sleeve(s)
Tip
NO Ground Here
Unbalanced Output Wiring
Amplified audio output
G
connector (shown below). The amplified audio is capable of outputting 50 watts
(2 x 25 watts RMS) for 4 and 8 ohm speakers.
To terminate the cable, strip the end of the cable 0.2 inch (5 mm) and secure the
wires into the supplied 4-pole captive screw connector as shown below.
AMPLIFIED OUTPUT
4/8
L
PVCA 452
Rear Panel
HDMI port
H
HDMI cable between this port and the HDMI ARC supported input on the TV. CEC
control signals are also available on this port.
— Connect a downstream audio device, such as an external
Left
Right
— Connect speakers to this 5 mm captive screw 4-pole
Speaker 1 Speaker 2
Speaker Wire
Color
Audio output
to speakers
Red
4-pole Captive
Screw Connector
Black
R
— For applications using HDMI ARC (Audio Return Channel), connect an
PlenumVault Direct View Systems • Installing the PVCA 452
Tip
Left
Ring
Sleeve(s)
Tip Right
Ring
Balanced Output Wiring
To PVCA 452 Terminal
(Left and Right)
Positive (+)
Negative (-)
