Stage 4:

Completing
Installation of the
PVCA 452

Rear Panel Features and Cabling

A B C D
POWER AUDIO
12V DIGITAL
L
2.0 A MAX
VOICELIFT
Figure 13.
Power input
A
TOSLINK fiber optic port
B
VoiceLift microphone port
C
Stereo analog audio input
D
Aux mono audio input
E

Inputs

A
E F
AUX
AUDIO
R
L R
PVCA 452 Rear Panel Features
Line audio output
F
Amplified audio output
G
HDMI port
H
Paging sensor port
I
RS-232 COM port
J
Power input — (See Power Supply
Connect the provided power supply to this 2-pole captive screw connector. Wire the
connector as shown at right.
Smooth
Ridges
A A
SECTION A–A
Power Supply
Output Cord
PlenumVault Direct View Systems • Installing the PVCA 452
G H I
PAGE
AMPLIFIED AUDIO
SENSOR
DO NOT
GROUND
4/8
OR SHORT
SPEAKER
OUTPUTS
HDMI/CEC/ARC
L R
CLASS 2 WIRING
on page 36 before making any connections.)
NOTE: Use only the supplied 12 V,
4.2 A power supply provided with
this amplifier. The PVCA 452 power
Captive
supply can support a typical system
Screw
Connector
(for example, a PVCA 452, 2 or 4
speakers, an EBP 100, and a
VoiceLift Microphone system).
Tie Wrap
3"
16 (5 mm) Max.
J K M N
COM IR/S D I/O eBUS
RS 232 PWR OUT = 3W
+V Tx Rx G S G 1 2 G +V +S -S G LAN
IR/Serial port
K
Digital I/O port
L
eBUS port
M
LAN port
N
34
