Location of the Main Display
Factors to consider include:
•
•
•
•
Location of eBUS Button Panel and Input Wallplate
Factors to consider include:
•
•
•
•
4 PlenumVault Direct View Systems • Introduction
Ceiling and wall type (important in assessing the hardware needed)
Ceiling type: dropped, spline, hard lid, and similar
•
Structural type (wood, concrete, trusses), plenum or non-plenum
Wall type: drywall, cement, brick
•
WARNING: Structural ceiling failure could cause death serious injury or
death. Check the structural ceiling to ensure that it can handle a load four times
the weight of the final setup.
AVERTISSEMENT : Un défaut dans la structure du plafond pourrait
provoquer des blessures graves voire mortelles. Vérifier la structure du
plafond afin de vous assurer qu'il peut supporter une charge quatre fois supérieure
au poids de l'installation finale.
Proposed display location
Power source for the display: existing and accessible or needing installation
Viewing obstructions: pillars, furniture and so forth, window locations for glare
reduction, obstructions with display
Overhead clearances (refer to a copy of ADA Standards for Accessible Design,
Sections 307 and 308, for ADA requirements)
Forward and side reach (for full details refer to a copy of ADA Standards for
Accessible Design, Sections 307 and 308, for ADA requirements)
Location of source devices: desk, table, or rack mounted, and proximity to proposed
transmitter location (wall, podium, or furniture)
Cabling obstacles: studs, utility pipes, power supply location (consider if raceway
installation is needed)
Network drop for PVCA 452: ceiling cabled to PlenumVault PVM 220 location
