Optional Accessory Installation — Priority Page Sensor (PPS 35)
The Extron PPS 35 Priority Page Sensor works with the PVCA 452 and is an
optional part of PVDV 101 system.
For detailed information, see the Priority Page Sensor Kit Installation
Instructions, supplied with the device.
The PPS 35 mounts to the front face of any public address (PA) loudspeakers
with the pre-installed hook-and-loop fastener. The cable is connected to the
rear panel 3-pole captive screw Page Sensor port of the
PVCA 452, located up to 50 feet away. Fifteen feet of cabling is supplied
already attached to the sensor.
When the Priority Page Sensor senses a PA system broadcast, it sends a signal
to mute the audio output of the PVCA 452 for the duration of the PA broadcast.
NOTES:
• The PPS 35 unit is NOT plenum rated and should not be installed above a plenum drop ceiling.
• The cable attached to the PPS 35 unit IS plenum rated and may be installed above a drop ceiling.
• The PPS 35 is NOT compatible with the PPC 25 Priority Page Controller.

Installation Procedure (PPS 35)

1. Using the hook-and-loop fastener, attach the PPS 35 to the front grille of a
paging system speaker that is located within fifty feet of the PVCA 452 (see
image at right).
2.
Run the attached cable to the PVCA 452 location.
42 PlenumVault Direct View Systems • Installing the PVCA 452
Admin Building
Classroom
Ceiling Mounted
Paging Speaker
To Classroom
Paging Speakers
Extron
PVCA 452
Controller Amp
Typical PPS 35 Paging System with PVCA 452.
PPS 35 PPS 35
Priority Page Sensor Priority Page Sensor
(installed on Speaker Front Grille) (installed on Speaker Fr
Sensor
Output
Plenum cable Plenum cable
G E
O R
P A
N S
S E
+ V + V
D IO R C
A U
C /A
D C E
IF IE M I/
P L H D
A M
R
T 4 /8
NO
DO ND
OU OR T L
GR SH R
OR KE
EA S
SP UT IN G
OU TP IR
2 W
SS
C LA
D IO R
A U
L
Audio
X
A U
D IO
A U R
L
L
IT A
D IG IF T
E L
IC
W ER V O
P O
V A X
12 A M
2. 0
Extron
FF 120
Flat Field Speakers
ro
U S
e B
3W
T =
O U
N
I/ O R L A
P W
D
/S G
IR -S
+ S
+ V
M M
C O C O
G
2 2
S 2 2 3 1
R S
G
S
R x R x G
T x
Paging
Sensor
Input
PPS 35 Priority Page Sensor
(part number 70-1074-01)
