9. Modbus TCP

9.1. Overview

The OPT-3-MTPEG-IN device operates as a Modbus TCP to Modbus RTU converter and communicates to the drive using the
Modbus RTU protocol. For drives with factory fitted interface, the operating principle remains the same.

9.2. Usage Requirement

 When using the Modbus TCP to control the drive it is necessary to ensure that the amount of data and frequency of data exchange
does not exceed the amount of data which can be successfully exchanged on the Modbus sub-network within the permitted time.
 Whilst the Optitools Studio PC software supports communication through the Ethernet network for device commissioning, it is not
recommended to use this continuously during operation of the drive as the additional communication load may exceed the limit
resulting in loss of Cyclic communication.
o In this case, connect the PC software to the drive serial port using the USB / RS485 adaptor.
 Use port D1 or D2 of the external Ethernet adaptor. Use port D1 or D2 of the external Ethernet adaptor.
 Use port D1 or D2 of the Compact 2 Ethernet adaptor. Use port D1 or D2 of the Compact 2 Ethernet adaptor.
 Use one of the available ports labelled "IOIOI". Use one of the available ports labelled "IOIOI".
o Do not connect via Ethernet if data logging is required. Do not connect via Ethernet if data logging is required.

9.3. Operation

9.3. Operation
9.3.1. Supported Commands 9.3.1. Supported Commands
Modbus TCP supported commands and registers are the same as those for Modbus RTU. Refer to sections 4.3. Modbus RTU Modbus TCP supported commands and registers are the same as those for Modbus RTU. Refer to sections 4.3. Modbus RTU
Configuration Parameter on page 10 to 4.6. Modbus RTU Indirect Parameter Access on page 10 for further information. Configuration Parameter on page 10 to Configuration Parameter on page 10 to Configuration Parameter on page 10
9.3.2. IP Address 9.3.2. IP Address
The default IP address is 192. 1 68. 1 .253, Subnet Mask 255.255.255.0 The default IP address is 192. 1 68. 1 .253, Subnet Mask 255.255.255.0
IP configuration can be changed using the internal webserver interface. IP configuration can be changed using the internal webserver interface.

9.4. Trouble Shooting

9.4. Trouble Shooting
9.4.1. Status Indicator LEDs 9.4.1. Status Indicator LEDs
Refer to 6. Ethernet Connection on page 14 for status LED location information. 6. Ethernet Connection on page 14 for status LED location information.
Status LED Status LED Function Function
NS Ethernet Network Status Indicator Ethernet Network Status Indicator
MS MS: Ethernet/IP Network Status Indicator MS: Ethernet/IP Network Status Indicator
COMM COMM COMM: Modbus Communication Indicator (OPC-2-ETHIG-IN <-> Drive) COMM: Modbus Communication Indicator (OPC-2-ETHIG-IN <-> Drive)
ERROR Modbus Error Indicator (OPC-2-ETHIG-IN <-> Drive) Modbus Error Indicator (OPC-2-ETHIG-IN <-> Drive)
Network Status (NS) Indicator Network Status (NS) Indicator
State Ethernet/IP Ethernet/IP
Steady Off Steady Off
Not powered Not powered
No IP address
Steady Green Online
One or more connections active or message received
Online
Flashing Green
No connections active or no messages received
Flashing Red Connection timeout
Steady Red Duplicate IP
Flashing Green and Red Self-test
www.invertekdrives.com
4.6. Modbus RTU Indirect Parameter Access on page 10 for further information. 4.6. Modbus RTU Indirect Parameter Access on page 10 4.6. Modbus RTU Indirect Parameter Access on page 10 for further information.
Modbus TCP Modbus TCP
Not powered Not powered
No IP address
In EXCEPTION state
At least one Modbus TCP message received
Online
Waiting for first Modbus TCP message
Connection timeout
No valid Modbus TCP message have been received
with in the configures "process active timeout"
Duplicate IP
Fatal Error
Version 1.02 | Fieldbus Guide | 45
