Step 3.
Assign the device Name and the IP Address to the Drive
(Default IP Address of the module is 192. 1 68. 1 .253)
Step 5. Step 5.
Add the 'New Module' under the 'CIP Bus' Add the 'New Module' under the 'CIP Bus'
Click the right button on the CIP Bus (under the ETHERNET- Click the right button on the CIP Bus (under the ETHERNET-
BRDIGE) and add the New Module BRDIGE) and add the New Module
8
38 | Fieldbus Guide | Version 1.02
Step 4.
Ethernet-Bridge device will be added to your project
The Modbus Translator will be added to your Ethernet/IP
network represented as an "ETHERNET-BRIDGE"
Step 6. Step 6.
Select the 'CIP-Module' from the list Select the 'CIP-Module' from the list
