Summary of Contents for Invertek Drives OPTIDRIVE E3 ODE-3
- Page 1 2016 SERVICE MANUAL ODE-3 FRAME SIZE 1 IP66 SERVICE MANUAL Frame Size 1 240V - 480V Assembly/disassembly IP66 Page 1 of 6...
- Page 2 SERVICE MANUAL ODE-3 FRAME SIZE 1 IP66 2016 Contents Page no: Drive cover removal procedure ..................... 3 Plastic case removal ......................4 PCB Removal from heatsink ....................5 Page 2 of 6...
- Page 3 SERVICE MANUAL ODE-3 FRAME SIZE 1 IP66 2016 Drive cover removal procedure Place the drive on a flat surface Using a Philips screwdriver remove the terminal cover. The drive will look as shown opposite For the Switched variant, disconnect all connection to the terminal connector of the drive Page 3 of 6...
- Page 4 SERVICE MANUAL ODE-3 FRAME SIZE 1 IP66 2016 Plastic case removal Using a torx screwdriver T20, remove the 4 x cover screws 1.5Nm Place the drive on its side then pull the top cover away from the metal heatsink. The drive will split apart down the red line Page 4 of 6...
- Page 5 SERVICE MANUAL ODE-3 FRAME SIZE 1 IP66 2016 A ribbon cable is connected from the top cover to the control board. Pull the connector away from the control board in the direction highlighted The top cover can now to be fully removed PCB Removal from heatsink Using a torx screwdriver T20, remove the 2 x screws...
- Page 6 SERVICE MANUAL ODE-3 FRAME SIZE 1 IP66 2016 Using a torx screwdriver T10, remove the 3 x screws highlighted opposite 1Nm With the heatsink removed, access can now be made to the IGBT module Page 6 of 6...
