6.2.4. Electrical Installation
WARNING! Do not connect Ethernet devices to ports D1 or D2. They may be damaged!
Power supply to the module is provided from the connected drive via the RJ45 connection.
WARNING! Do not use cross over cables! Cables must be pin to pin connected!
WARNING!
One device only on this port!
External Keypad
Optistick Smart
PC Connection Kit PC Connection Kit
No additional network connection No additional network connection
Max cable length: 25 metres Max cable length: 25 metres
Ethernet Network Ethernet Network
Ground tab – Observe the recommended grounding procedure for the fieldbus network and if necessary, connect this tab to ground Ground tab – Observe the recommended grounding procedure for the fieldbus network and if necessary, connect this tab to ground
where required. where required.

6.3. Internal Interface for IP66 Drives

6.3. Internal Interface for IP66 Drives
6.3.1. Layout – Internal Interface 6.3.1. Layout – Internal Interface
6
L1
6.3.2. Labelling – Internal Interface
The MAC address of the device is shown below the ports.
16 | Fieldbus Guide | Version 1.02
COMM COMM COMM ERROR ERROR ERROR
D1
P1 Ethernet P2 P1 Ethernet P2
MS MS
NS NS
I0I0I I0I0I I0I0I I0I0I
1 2 3 4 5 6 7 8 9 10 11 1 2 3 4 5 6 7 8 9 10 10 11 10
L2/N L3 EMC U V W
WARNING!
One Drive only on this port! One Drive only on this port!
No additional network connection No additional network connection
Max cable length: 3 metres Max cable length: 3 metres
D2 D2
GND GND
IOIOI: Dual serial ports. IOIOI: Dual serial ports.
WARNING! Do not connect Ethernet devices here! WARNING! Do not connect Ethernet devices here!
These ports are for external serial connection of These ports are for external serial connection of
remote keypad and PC connection only! remote keypad and PC connection only!
Port P1: Primary Ethernet port
Port P2: Secondary Ethernet Port
