Step 13.
Drive tags created in the Controller Tags Window
8.6.3.2.2. For use with ODE-3 IP66 Outdoor drives with built-in Ethernet/IP interface (Drive model code +"EiP") 8.6.3.2.2. For use with ODE-3 IP66 Outdoor drives with built-in Ethernet/IP interface (Drive model code +"EiP")
Step 1. Step 1.
Add the New Module to the Ethernet/IP network Add the New Module to the Ethernet/IP network
Click the right button on the Ethernet (under the I/O Click the right button on the Ethernet (under the I/O
Confi guration) and add the New Module Confi guration) and add the New Module
Step 3.
Assign the device Name and the IP Address to the Drive
(Default IP Address of the module is 192. 1 68. 1 .253)
8
32 | Fieldbus Guide | Version 1.02
Step 2. Step 2.
Search for Invertek devices in the Catalog View Search for Invertek devices in the Catalog View
Select the OPT-3-ETHIG-IN device from the list Select the OPT-3-ETHIG-IN device from the list
Step 4.
Click the 'Change...' button in the Module Defi nition
