Cortex SM26 Multi Gym User Manual page 22

STEP 15
1. According to the diagram, set up the light shaft bottom set (46#), safety hook (24#), damping pad
(52#), bearing sleeve (25#) with bolt (68#) and gasket (74#), then set the light shaft upper set (47#).
2. Pass the rod (12#) into (25#) and buckle the hook (41#), (42#) to (12#).
22 | ASSEMBLY INSTRUCTIONS
47
6
25
42
52
24
46
74
68
6
12
41
23
46
74
68
47
25
52
