Cortex SM26 Multi Gym User Manual page 21

68
74
37
74
68
3
36
59
68
51
22
21
74
68
14
14
STEP 14
1. First install (36#) and (37#) onto the holes on (4#) and (10#) using bolts (68#), insert (74#) and then
fix the 2 plates with bolts (70#) and nut (73#).
2. Attach the handle (51#) on C type buckle (59#) and then attach (59#) to the pulley rope.
3. Insert the parts (13#), (14#) and (21#) into the column (#) holes to use.
4. Repeat for the other side.
ASSEMBLY INSTRUCTIONS | 21
