Cortex SM26 Multi Gym User Manual page 12

STEP 5
1. Place the rear upper beam (8#) and flat connection plate (50#) on both sides of (1#) as shown. Fix
with bolt (66#) pads, plate (74#) and nut (71#).
2. Insert sleeve (33#) into (1#) and secure with bolt (68#) spacer (74#). Insert sleeve (44#) into (33#) and
card (53#) into (44#).
3. Repeat for the other side.
12 | ASSEMBLY INSTRUCTIONS
1
8
71
74
74
68
50
74
66
44
33
53
1
