Cortex SM26 Multi Gym User Manual page 14

65
31
9
2
65
32
STEP 8
1. Place the rear trim plate (77#) on the side of (1#) and (8#) and secure with the bolt (66#), gasket (74#),
and nut (71#).
2. Place the upper trim plate (31#) and the lower holes on (9#) and (2#). Secure the bolt (65#), gasket
(74#) and nut (71#).
3. Repeat for the other side.
14 | ASSEMBLY INSTRUCTIONS
74
71
74
74
74
66
77
1
71
71
8
1
