To prevent image over-modulation, the measured object should be in the middle (in the target
mark) and the brightness spot size as large as the measuring object.
▪
Adjusting the focus distance for pyrometers with a motor focus:
For adjusting the focus distance to the measuring object (spot size tables see 5.6).
Input via keyboard
Click for 1 cm steps

7.1.5 Device Configuration

Configure a
Temperature
Sub Range
Simulation of
a measurement
temperature
Configure Ana-
log Outputs
and Test them
Configure
Configurable
Inputs / Out-
puts and carry
out Port tests
Service Functions: Back-
ing up, printing or restoring
device parameters or creat-
ing service files for remote
diagnosis of problems.
7.1.5.1

Temperature Sub Range

▪ Adaptation: The temperature range can be reduced to adapt it to special measuring conditions (minimum
temperature span 51°C).
resets the temperature range to the adjacent total temperature range.
▪ Simulation simulates a measured temperature at the outputs (see
7.1.5.2

Laser Targeting Light Settings

The time can be entered here when a switched-on laser targeting light switches off automatically.
Times: between 5 and 900 s (15 min).
40 / 81
Here basic device settings are made.
Automatic Laser Tar-
geting Light switch off
Interface
baud rate,
delay, de-
vice address
METIS M311 / M322 / H311 / H322 (12-pin device connector)
Show measurement
temperature on display
or suppress display
Data Col-
Single-Point
lection Adjustment
settings function to ad-
just to a single
temperature
7.1.5.9
Available range
Slide with mouse
Keylock
activation
Device menu language
German or English
The analog output 1 al-
ways provides the meas-
ured temperature, output
2 is configurable
Output options
Optional: Switching
Settings the Tem-
Profibus perature
/ Profinet Unit to
°C or °F
Test functions).
