Communication / Options

Prints a saved device configuration file (
function "Create configuration file" (see
Update device
firmware
Terminal field for communication with the pyrometer via interface commands (see section 11)
Open folder in
Windows Explorer
▪ Flash H3 / M3 / DI / DS firmware starts the
A corresponding firmware file is required for this. It can be downloaded using the "Check firmware" service
function (see 7.1.5.10
stalled in the device is available.
To be able to connect the pyrometer to SensorFlash, it must first be disconnected from SensorTools in the
Devices tab, the appropriate COM port must then be selected in SensorFlash, and the device connected
again.
▪ The working directories specify the device settings locations (all software-internal and device-specific data
such as Service Functions
ing.
The storage paths can only be changed if no device is connected.
7.7

Spot size calculator

The spot size calculator is used to calculate the spot size diameter in front of and behind the focus distance. To
do this, first enter the white fields with the focus distance, the associated spot size diameter and the aperture
according to the
field and confirmed with the Enter key, the corresponding equivalent value in the associated gray field is calcu-
lated directly.
7.1.5.10
Select program
language
Change default Current storage paths
storage paths
Service functions) if the check shows that a more recent version than the one in-
or ShortSetting
Spot Size Tables. A measuring distance or spot size diameter can then be entered in a gray
data format *.r2p). To create the file, use the service
Service functions) while a pyrometer is connected.
SensorFlash software to update the firmware of the pyrometer.
files stored via the control window) and for measurement record-
Search for software
updates and install
