Composition of the Model Number

The equipment version of the pyrometer is encoded in the 22-digit model number as follows
(Example type number M311 with 600–1300°C; laser targeting light, motorized focus, optics...):
Digit 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22
Expl.: M 3
Digit Indication of the various points
01-02 Series M3
Series H3
03-04 Spectral range
05-08 Beginning of temperature range [°C]
09-12 End of temperature range [°C]
13 Sighting
14 Serial interface
15 Lens type
16-17 Minimum response time
18 Configuration
19 Digital display
20 Analog outputs
21 Digital input / digital output
22 Measuring distance / optics
70 / 81
1 1 0 6 0 0
METIS M311 / M322 / H311 / H322 (12-pin device connector)
1 3 0 0 1 5
Code Meaning / Example
M3 Metis M3
H3 Metis H3
11 0.75–1.1 µm (2 x Si)
0.78 + 0.99 µm (2 x Si)
22 1.45–1.8 µm (2 x InGaS) or
1.4+1.64 µm (2 x InGaS)
0600 600°C
1300 1300°C
1 Laser targeting light
2 View finder
4 TV color camera
5 RS232 / RS485 (switchable)
3 Profinet integrated
4 Profibus integrated
6 Ethernet
1 Fixed focus optics
2 Focusable optics
3 Fiber optic cable 0.2 mm Ø
with focusable optics
4 Fiber optic cable 0.4 mm Ø
with focusable optics
8 Motorized focus
B Heavy duty stainless steel sensor head
for 0.2 mm fiber with OQ25
C Heavy duty stainless steel sensor head
for 0.4 mm fiber with OQ25
13 <1 ms
81 80 µs (H3 version)
0 Standard (12 pin connector, display, push buttons,
3 digital inputs / outputs)
4 Standard + PID controller
4 With display (12 pin connector)
2 2 analog outputs
3 3 digital inputs / outputs / 1 analog input
0–20 mA (with 12 pin connector)
A Optics A (340-3000 mm, integrated optics)
B Optics B (240-3000 mm, optical fiber)
C Optics C (120-500 mm, optical fiber)
X Special optics
8 1 3 0 4 2
integrated
3 A
