Command Parameter Description / Settings
aa (aaX)
XY
an
X
ar
X
as
X
ax
XXXX
az
XXXXXX
bn
bn1
bum
XX
bup
74
/ 81
METIS M311 / M322 / H311 / H322 (12-pin device connector)
Output of the adjustable analog output 2 (X=2 = analog output 2)
Y = 0...8, output temperature or controller
Y = 0 = No output
Y = 1 = 2-color temperature
Y = 2 = Temperature channel 1
Y = 3 = Temperature channel 2
Y = 6 = manipulated variable (devices with PID controller)
Y = 8 = Device temperature
Measured temperature (for temperature reading also see mw command)
X = 0 = 2C channel; 1 = channel 1; 2 = channel 2
Output mode: analog output 2
X = 0 = 0–20mA; 1 = 4–20mA
Output mode: analog output 1
X = 0 = 0–20mA; 1 = 4–20mA
Switch-off level in 1/10%
XXXX = 0x0014...0x0384 (corresponds to 2.0 to 90.0%)
Response time of the shutdown (in steps of 100 µs to 10 s)
XXXXXX = 0x000000...0x0186A0
Reference number pyrometer (18-digit ASCII)
Reference number pyrometer (21-digit ASCII)
Buffer mode selection (XX = 00...03)
Transmission of measured data:
Reading the buffer data (only one current packet!)
Buffer mode 00: answer: AAAA
AAAA = Measured temperature (0xF001 => Overflow)
Buffer mode 01: answer: AAAABBBBCCCC
AAAA = 2-color temperature (0xF001 => Overflow)
BBBB = 1-color temperature channel 1 (0xF001 => Overflow)
CCCC = 1-color temperature channel 2 (0xF001 => Overflow)
Buffer mode 02: answer: AAAABBBBCCCCDDDDEEEEFFFFGGHHIIJJ
AAAA = 2-color temperature (0xF001 => Overflow)
BBBB = 1-color temperature channel 1 (0xF001 => Overflow)
CCCC = 1-color temperature channel 2 (0xF001 => Overflow)
DDDD = Setpoint value at ramp function (current ramp setpoint value!)
EEEE = (Analog) controller manipulated variable (0-1000) in % (0.0-100.0%)
FFFF = Signal strength (0-1000) in % (0.0-100.0%)
GG = Data status byte 0
HH = Data status byte 1
II = Data status byte 2
JJ = Data status byte 3
Buffer mode 03: answer: AAAABBBBCCCCDDDDEEEEFFFFGGHHIIJJ
AAAA = 2-color temperature (0xF001 => Overflow)
BBBB = 1-color temperature channel 1 (0xF001 => Overflow)
CCCC = 1-color temperature channel 2 (0xF001 => Overflow)
DDDD = Setpoint value at ramp function (current ramp setpoint value!)
EEEE = (Analog) controller manipulated variable (0-1000) in % (0.0-100.0%)
FFFF = Signal strength (0-1000) in % (0.0-100.0%)
GG = Data status byte 0
HH = Data status byte 1
II = Data status byte 2
