KPM PROCESS SENSORS METIS M311 Operating Manual page 75

METIS M311 / M322 / H311 / H322 (12-pin device connector)
br X
eg XYYYY
et XXXXXX
fh X
ff XYYYY
fs
ga XX
gh (ghX) XYYYY
gk (gkX) XYYYY
ia (iaX) XYYYY
if X
io XX
in (inX) XYY
JJ = Data status byte 3
KKKK = Analog input in Bit (0x0000–0x0FFF)
LLLL = unused (0xFFFF)
NNNN = Measured temperature (0xF001 => Overflow)
MMMM = unused (0xFFFF)
Data status bytes:
Bit GG
Bit0 (lsb) Fahrenheit active
Bit1 Status digital output 1
Bit2 Status digital output 2
Bit3 Status digital output 3
Bit4 Status digital input 1
Bit5 Status digital input 2
Bit6 Status digital input 3
Bit7 (msb) unused
Baud rate of serial interface
X=2...6,8..9,a,b
2 = 4800 Baud 5 = 38400 Baud
3 = 9600 Baud 6 = 57600 Baud
4 = 19200 Baud 8 = 115200 Baud
Emissivity / emissivity slope
X = 0...2; YYYY = 0x0050-1200 (corresponds 5 to 120%; in 0.1% steps)
eg0 = emissivity slope = 0x0320...04b0 (0800-1200)
eg1 = emissivity slope channel 1 = 0x0032...04b0 (0050-1200)
eg2 = emissivity slope channel 2 = 0x0032...04b0 (0050-1200)
Response time (in steps of 100 µs)
XXXXXX = 0x000000-0186A0 (corresponds to 0 to 10 s)
Celsius/Fahrenheit selection
X = 0 = Celsius; 1 = Fahrenheit
Fill factor (spot size filling)
X = 1, 2; YYYY = 0050-1000 (corresponds 5%-100%) in 0.1% steps
ff1 – Fill factor channel 1 = 0x0032...03e8 (0050-1000)
ff2 – Fill factor channel 2 = 0x0032...03e8 (0050-1000)
Read error status:
Bit 0 = Error A/D converter
Bit 1 = I2C error (video module)
Bit 2 = error device temperature
Bit 3 = error detector temperature
Device address XX = 00...97 (2-digit dec.)
Hysteresis for limit switch X (X = 1...3) to value YYYY (in 1/10 degree)
Threshold for limit switch X (X = 1...3)
to value YYYY (in 1/10 degree)
Debounce time for digital input X (X = 1...3)
Debounce time: YYYY = 0x0000...03E8 (0-1000 ms)
Serial interface (only M3)
X = 0 = RS232; 1 = RS485 (that followed a baud rate of 19.2 KBd!)
Configure digital inputs/outputs
Bit 0 =1 => inputs 1 active / output 1 inactive, otherwise reversed;
Bit 1 =1 => inputs 2 active / output 2 inactive, otherwise reversed;
Bit 2 =1 => inputs 3 active / output 3 inactive, otherwise reversed.
Configure input X = 1...3; YY = 00...05
YY = 00 – No function
YY = 01 – External clearing peak picker
YY = 02 – Targeting light on (devices with targeting light)
YY = 03 – Activate controller (devices with controller)
HH
Controlling active
AutoTune active
AutoTune at controller start
Device ready
Device hardware error
Controller finished successful
Targeting light active
unused
9 = 230400 Baud
a = 460800 Baud
b = 921600 Baud
Bit 4 = error device temperature over
Bit 5 = error Eeprom
Bit 6 = error motorized optics
Bit 7 = unused
II JJ
Setup0 Display 0
Setup1 Display 1
Setup2 Display 2
unused unused
unused unused
unused unused
unused unused
unused unused
