METIS M311 / M322 / H311 / H322 (12-pin device connector)
▪ Device malfunction, indicated by a red operating status LED (right LED 4).
This may be a data transmission error or a firmware problem.
→ If the interface is not affected, the error can be read out via the
(in the Terminal
us so that we can find a solution of the problem.
To further limit the possibilities, a
SensorTools (see under
cess Sensors IR for further support.
11

Communication via Interface Commands

Interface commands are used to communicate directly with the pyrometer via the serial interface. Commands
can be used to write an own access control or can be entered in the terminal field of the software SensorTools
(see 7.6 Communication / Options) or entered via a terminal software.
▪ Data is exchanged in ASCII format with the following transmission parameters:
8 bit, 1 stop bit, even parity (8,1,e)
▪ Command sequence to write parameters:
2-digit device address → command → parameter → <CR> (Carriage Return)
▪ Command sequence to read out the current set parameters:
2-digit device address → command → <CR> (Carriage Return)
INFO
▪ Device address (also see in 6.2.12): In factory setting the device address is 00 but can be changed directly
at the pyrometer (under INTERFACE> → ADD).
In the Terminal field
▪ Parameters are encoded in hexadecimal unless specified otherwise.
▪ When writing with valid parameters, the response will be ok + <CR>
▪ When writing with invalid parameters, the response will be no + <CR>
▪ Deviating reading commands are in parentheses at the respective commands.
Example:
Input in terminal programs with device address 00:
0ar1<CR> sets the 2
00ar<CR> reads out how the analog output is set
Input in the Terminal field
ar1<CR> sets the 2
ar<CR> reads out how the analog output is set
INFO
The following commands are valid with the newest firmware version.
field, see 7.6). For interpretation of the answer please contact
service file
7.1.5.10 Service Functions) that can be sent to Pro-
of the SensorTools software no address is required.
nd
analog output to 4-20 mA
of SensorTools without device address
nd
analog output to 4-20 mA
fs command
can be created via the software
