METIS M311 / M322 / H311 / H322 (12-pin device connector)
33-34 Beginning of device temperature range (in 1/10 degree)
35-36 End of device temperature range (in 1/10 degree)
37-38 Devices with controller: setpoint value (in 1/10 Grad)
Devices with controller: proportional band Xp (0...10000) in 0.1%
39-40
Devices with controller: integral time Ti (0...65535) Factor × sampling time
41-42
Devices with controller: derivative tme Td (0...65535) Factor × sampling time
34-44
Devices with controller: minimum controller output power P-Min (0...999) in 0.1%
45-46
Devices with controller: maximum controller output power P-Max (1...1000) in 0.1%
47-48
Devices with controller: AutoTune target temperature (0...1000) in 0.1%
49-50
Devices with controller: controller output power limitation P-dynamic (0...10000) in 0.01%
51-52
Devices with controller: ramp time (0...65535) in 100 ms
53-54
Devices with controller: hold time (0...65535) in 100 ms
55-56
57-58 Devices with controller: sampling time (100...2500) in 10 µs
59-60 Devices with motorized optics: smallest possible measuring distance (in mm)
61-62 Devices with motorized optics: largest possible measuring distance (in mm)
63-64 Devices with motorized optics: current set measuring distance (in mm)
Mode 2 (Data packet size 64 Byte): available and freely selectable pyrometer data
Length
Meaning
Bytes
2 Measured temperature (in 1/10 degree)
2 2-color temperature (in 1/10 degree)
2 Temperature channel 1 (in 1/10 degree)
2 Temperature channel 2 (in 1/10 degree)
2 Temperature sum channel (in 1/10 degree)
2 Flame temperature (in 1/10 degree)
2 Emissivity slope (in 1/10 degree)
Emissivity channel 1 (50...1200)
2
Emissivity channel 2 (50...1200)
2
Emissivity sum channel (50...1200)
2
Transmittance channel 1 (50...1000)
2
Transmittance channel 2 (50...1000)
2
Transmittance sum channel (50...1000)
2
Fill factor channel 1 (50...1000)
2
Fill factor channel 2 (50...1000)
2
Fill factor sum channel (50...1000)
2
2 Switch-off level (20...900)
Soot factor (50...250) (Flame)
2
2 Optical density (0...10000) (Flame)
2 Storage mode (0...4)
Clear time (0...250000, 0...25 s)
4
Response time (0...100000, 0...10 s)
4
2 Analog output 1+2
2 Error status (0...255)
2 Internal device temperature (00...100, in 1°C)
Int. device temp. (00...25600, in 1/256°C)
2
2 Detector temperature (00...100, in 1°C)
Detector temperature (00...25600, in 1/256°C)
2
2 Beginning of device temp. range (in degree)
2 End of device temp. range (in degree)
Beginning of temperature sub range analog 1
2
(in degree)
Length
Meaning
Bytes
End of of temptemperature sub range
2
analog analog 1 (in degree)
Beginning of temperature sub range
2
analog 2 (in degree)
End of of temptemperature sub range
2
analog analog 2 (in degree)
Devices with controller:
2
Setpoint value (in 1/10 Grad)
Devices with controller:
2
Proportional band Xp (0...10000) in 0.1%
Devices with controller: Integral time Ti
2
(0...65535) Factor × sampling time
Devices with controller: Derivative time Td
2
(0...65535) Factor × sampling time
Devices with controller: Minimum controller out-
2
put power P-Min (0...999) in 0.1%
Devices with controller: Maximum controller out-
2
put power P-Max (0...999) in 0.1%
Devices with controller: AutoTune target temper-
2
ature (0...1000) in 0.1%
Devices with controller: Controller power limita-
2
tion P dynamik (0...10000) in 0.01%
Devices with controller:
2
Ramp time (0...65535) in 100 ms
Devices with controller:
2
Hold time (0...65535) in 100 ms
Devices with controller:
2
Sampling time (100...2500) in 10 µs
Devices with motorized optics: smallest possible
2
measuring distance (in mm)
Devices with motorized optics: largest possible
2
measuring distance(in mm)
Devices with motorized optics: Current set
2
measuring distance (in mm)
- End mark
