KPM PROCESS SENSORS METIS M311 Operating Manual page 76

X
la
lg X
lm X
lt XXXXXX
lx
mb
me XXXXYYYY Temperature sub range of pyrometer (superordinate to the analog outputs)
me (meX) XYYYYZZZZ Scale analog output temperature range X (X = 1, 2) (0...6553.5 °C/°F)
mwX
oa (oaX) XYYYY
oc (ocX) XYY
od XX
oh (ohX) XYYYY
op (opX) XYY
pia XXXX
re (re0)
sl
sh XYYYY
sk XYYYY
sn
tg XYYYY
to XXXX
76 / 81
METIS M311 / M322 / H311 / H322 (12-pin device connector)
YY = 04 – Controller start / stop (devices with controller)
YY = 05 – Setup 0
State of targeting light;
X = 0 =Targeting light off; 1 = Targeting light on; 2 = Targeting light toggle
Language X = 0 = English; 1 = German
Set storage mode (peak picker)
X = 0 = peak picker off (no storage); 1 = Time delete (then lt applies)
2 = External clearing of peak picker 3 = Automatic clearing of peak picker
Clear time of peak picker (in 100 µs steps)
XXXXXX = 0x000000...03d090 (0 to 25 s)
External clearing of peak picker
(Read) temperature range
XXXX = Beginning of temp. range; YYYY = end of temp. range in °C/°F
XXXX = Beginning of temp. range; YYYY = end of temp. range in °C/°F
YYYY = Beginning of temp. range; YYYY = end of temp. range in °C/°F
Read measured temperature (current value) (4-digit hex.)
mw0 = current 2-color reading
mw1 = current channel 1 reading
mw2 = current channel 2 reading
Activation time of the digital outputs X (X=1...3)
YYYY=0x0000...ffff (corresponds to 0-65535 ms)
Reference temperature for activating a digital output (X=1...3)
YY = 00 = 2-color, 01 = channel 1, 02 = channel 2
Output inversion (logic NO to NC)
Bit0 = 0 (digital output 1 = NO), Bit0 = 1 (digital output 1 = NC),
Bit1 = 0 (digital output 2 = NO), Bit1 = 1 (digital output 2 = NC),
Bit2 = 0 (digital output 3 = NO), Bit2 = 1 (digital output 3 = NC)
Hold time digital output X (X = 1...3)
Hold time: YYYY (0x0000...fffe) 0-65534 ms
Outputs (digital output X, X=1...3) YY=0x00...0A
YY=00 – no output
YY=01 – device ready contact
YY=02 – Material contact
YY=03 – limit switch contact
Automatic targeting light switch off
XXXX = 0x0000...ffff (0 to 65535 s)
X = 0 => targeting light never turns off;
X = 1...65535 => switches off after X seconds
Device reset
Read signal strength (answer: 4-digit hex in 1/10%)
Hysteresis for signal strength contact
X = 1...3 (digital output) to value YYYY (hex in 1/10%)
Switching value for signal strength contact
for X = 1...3 (digital output / signal strength contact) to value YYYY (hex in 1/10%)
Read serial number (5-digit dec.)
Transmittance
X = 1, 2; YYYY = 0050-1000 (corresponds to 5%-100%) in 0.1% steps
tg1 – Transmittance channel 1 = 0x0032...03e8 (0050-1000)
tg2 – Transmittance channel 2 = 0x0032...03e8 (0050-1000)
Output test:
Bit0 = 0 (digital output 1 = inactive), Bit0 = 1 (digital output 1 = active)
Bit1 = 0 (digital output 2 = inactive), Bit1 = 1 (digital output 2 = active)
YY=04 – unused
YY=05 – Over temperature
YY=06 – Setpoint limit 1
YY=07 – Setpoint limit 2
YY=08 – Setpoint band
YY=09 – Controller active
YY=0A – Control successful
