METIS M311 / M322 / H311 / H322 (12-pin device connector)
tsc / tsf X
tw XX
uh (uhX) XYYYY
uk (ukX) XYYYY
ve XXYYZZ
In addition, for devices with built-in camera module
X
oe
of X
oj X
oj DDMMYY
ojus MMDDYY
om X
os
ot X
ot / otus HHMMSS
ov X
ox TT...TT
vb XX
vc XX
vd X
(only M3)
vh XX
vi (vh) XX
Bit2 = 0 (digital output 3 = inactive), Bit2 = 1 (digital output 3 = active)
Special function: xxxx => deactivate test!
Read temperature sensor (in °C/°F) (4-digit hex)
tsc0 = Device temperature in 1/256°C
tsc1 = Detector temperature in 1/256°C
tsf0 = Device temperature in 1/256°F
tsf1 = Detector temperature in 1/256°F
Interface delay XX
Hysteresis for over-temperature contact
(X = digital output 1...3) to value YYYY (1/256°C)
Device over-temperature threshold at digital output X
X = 1...3 to value YYYY (in 1/256°C)
Read device identifier and date of firmware
XX = 55 ≙ M3 2-color types, XX = 29 ≙ H3 2-color types,
YY = consecutive firmware number, ZZ = last 2 numbers of year
Show / hide emissivity
X = 0 = Hide emissivity; 1 = Show emissivity
Set the time format
X = 0 = German time format; 1 = US time format
Show / hide date
X = 0 = Hide date; 1 = Show date
Set date (6-digit ASCII)
DD = day, MM = month, YY = year
Set date US (6-digit ASCII)
MM = month, DD = day, YY = year
Show / hide target marker
X = 0 = hide marker; 1 = Show marker
Read camera status (answer: XX; 2-digit hex)
Bit 0 = 1 Time displayed
Bit 1 = 1 Date displayed
Bit 2 = 1 Emissivity displayed
Bit 3 = 1 Temperature displayed Bit 8 =
Bit 4 = 1 Marker displayed
Show / hide time
X = 0 = Hide time; 1=Show time
Set time (6-digit ASCII), ot = German time, otus = US time
HH = hour, MM = minute, SS = second
Show / hide temperature
X = 0 = Hide temperature; 1 = Show temperature
Write own user text: TT...TT = Text (max. 16 ASCII characters)
White balance / automatic white balance
XX = 0x00...64 (= 0...100% of the window area, calculated centric to the image cen-
ter) or ff (= automatic white balance)
Color saturation
XX = 0x00...ff (= level 0-255)
Camera module (power) on/off
X = 0 = off; 1 = on
Sharpness of the image
XX = 0x00...ff (= level 0 to 255)
Brightness (AEC)
XX = 0x00...ff (= Level 0 to 255)
Bit 5 = US-Format Bit 10 = Autoexposure
Bit 6 = PAL Bit 11 = Autowhitebalance
Bit 7 = NTSC Bit 12 = Videomodule active
Bit 13-15 = Unused
Test image active
Bit 9 = Monochrome
